OMSI - Vault, Clue Kiosk
author: hydronics
2 layer board of 6.53 x 3.13 inches (165.9 x 79.6 mm)
Uploaded:
March 27, 2015
Shared:
March 27, 2015
Total Price:
$102.25
Vault with larger through holes for the molex connectors
Vault with larger through holes for the molex connectors
A1171 Hall Effect Switch Adaptor
author: JJKAA
2 layer board of 0.60 x 0.32 inches (15.2 x 8.2 mm)
Uploaded:
March 08, 2015
Shared:
March 27, 2015
Total Price:
$0.95
A1171 is a 1.65 to 3.5 V Hall Effect Switch for both unipolar and omnipolar magnetic actuation. The mode can be selected by a jumper. (digikey part no: 620-1232-1-ND)
A1171 is a 1.65 to 3.5 V Hall Effect Switch for both unipolar and omnipolar magnetic actuation. The mode can be selected by a jumper. (digikey part no: 620-1232-1-ND)
PD68 Lighted Switch
author: pilotdog68
2 layer board of 0.80 x 0.80 inches (20.3 x 20.3 mm)
Uploaded:
March 27, 2015
Shared:
March 27, 2015
Total Price:
$3.15
20mm PCB for Flashlight Lighted Tailcap. Discussion here: http://budgetlightforum.com/node/37851
20mm PCB for Flashlight Lighted Tailcap. Discussion here: http://budgetlightforum.com/node/37851
UTexas BWI Sensor Board v0.2
author: patopop007
2 layer board of 3.63 x 2.19 inches (92.2 x 55.6 mm)
Uploaded:
March 27, 2015
Shared:
March 27, 2015
Total Price:
$39.70
Sensor board for ultrasound, IMU, voltage reader, and IMU
Sensor board for ultrasound, IMU, voltage reader, and IMU
Freq_32
author: grosseruser
2 layer board of 2.36 x 1.06 inches (60.0 x 27.0 mm)
Uploaded:
March 27, 2015
Shared:
March 27, 2015
Total Price:
$12.55
32 bit binary counter with SN74LV8154 & Atmega 8(8) / 168 / 328 & DC-DC converter MCP1640C
Details on my private page.
32 bit binary counter with SN74LV8154 & Atmega 8(8) / 168 / 328 & DC-DC converter MCP1640C
Details on my private page.
Dual THAT1646 Balanced Output v1.0
author: straypacket
2 layer board of 2.44 x 2.00 inches (61.9 x 50.8 mm)
Uploaded:
March 27, 2015
Shared:
March 27, 2015
Total Price:
$24.35
Simple IC balancer (! UNTESTED !)
Simple IC balancer (! UNTESTED !)
Jensen AS016 Mic Preamp Pushbutton Frontend V1
author: straypacket
2 layer board of 1.85 x 3.00 inches (47.0 x 76.2 mm)
Uploaded:
March 27, 2015
Shared:
March 27, 2015
Total Price:
$27.75
Uses C&K F2UEE Switches (! UNTESTED !)
Uses C&K F2UEE Switches (! UNTESTED !)
Arduino_Minimal_PTH
author: mithat
2 layer board of 0.70 x 1.80 inches (17.9 x 45.8 mm)
Uploaded:
March 26, 2015
Shared:
March 26, 2015
Total Price:
$6.35
Crazy stupid experiment to see how small you can make an Arduino-compatible board using through-hole parts.
https://github.com/mithat/Arduino_Minimal_PTH.
Beta release.
Crazy stupid experiment to see how small you can make an Arduino-compatible board using through-hole parts.
https://github.com/mithat/Arduino_Minimal_PTH.
Beta release.
OMSI Spelling Fever - letter board
author: hydronics
2 layer board of 2.02 x 2.02 inches (51.2 x 51.2 mm)
Uploaded:
March 26, 2015
Shared:
March 26, 2015
Total Price:
$20.30
for mounting Red/green Avago LEDs and tactile button. this is the 1.6" board as sent to PCB4u.com on 11/7/2014
for mounting Red/green Avago LEDs and tactile button. this is the 1.6" board as sent to PCB4u.com on 11/7/2014
OMSI - Spelling Fever
author: hydronics
2 layer board of 2.53 x 3.76 inches (64.1 x 95.6 mm)
Uploaded:
March 26, 2015
Shared:
March 26, 2015
Total Price:
$47.50
Shift-in buttons and shift-out LEDs. 3/26/15 fixed broken trace
Shift-in buttons and shift-out LEDs. 3/26/15 fixed broken trace
Adapter - HD15F to D15M
author: luckyrobj
2 layer board of 1.56 x 0.93 inches (39.7 x 23.5 mm)
Uploaded:
March 05, 2015
Shared:
March 26, 2015
Total Price:
$7.20
Adapter board to convert HD15 male to D-sub 15 female connectors
Adapter board to convert HD15 male to D-sub 15 female connectors
Breakout 2x8 to 16p Header
author: luckyrobj
2 layer board of 0.66 x 1.60 inches (16.8 x 40.6 mm)
Uploaded:
March 05, 2015
Shared:
March 26, 2015
Total Price:
$5.25
Breakout board for 8x2 pin 0.1" connector or header (2 configurations)
Breakout board for 8x2 pin 0.1" connector or header (2 configurations)
Arduino_Pro_Mini_PTH
author: mithat
2 layer board of 1.10 x 1.80 inches (28.0 x 45.8 mm)
Uploaded:
March 26, 2015
Shared:
March 26, 2015
Total Price:
$9.95
Crazy stupid experiment to see how close you can get to an Arduino Pro Mini with through-hole parts.
https://github.com/mithat/Arduino_Pro_Mini_PTH.
Beta release.
Crazy stupid experiment to see how close you can get to an Arduino Pro Mini with through-hole parts.
https://github.com/mithat/Arduino_Pro_Mini_PTH.
Beta release.
nRF24L01+.Teensy3.1.Add-On.v02yx
author: PeskyProducts
2 layer board of 0.71 x 0.70 inches (18.0 x 17.8 mm)
Uploaded:
March 25, 2015
Shared:
March 25, 2015
Total Price:
$2.45
Nordic Semiconductor’s low-power 2.4 GHz RF radio with pcb antenna and matching circuit per Nordic’s spec. Using much smaller XRCHA16MHz Murata crystal to reduce cost and board size. Adjusted antenna dimensions for better matching.
Nordic Semiconductor’s low-power 2.4 GHz RF radio with pcb antenna and matching circuit per Nordic’s spec. Using much smaller XRCHA16MHz Murata crystal to reduce cost and board size. Adjusted antenna dimensions for better matching.
Display Converter Board
author: GeertVc
2 layer board of 0.95 x 0.91 inches (24.0 x 23.1 mm)
Uploaded:
March 25, 2015
Shared:
March 25, 2015
Total Price:
$4.25
Display converter board to connect Sharp display LS027B7DH01LCD through SMD connector and Raspberry Pi through 10-pins header. SPI protocol to be used to control the display.
Display converter board to connect Sharp display LS027B7DH01LCD through SMD connector and Raspberry Pi through 10-pins header. SPI protocol to be used to control the display.
