Zipit Z2 Breakout v2.3

v2.3 Updates:

Removed snap/break holes, removed microusb breakout header, removed host port breakout header, added optional bulk capacitor for host port, added 2 x M2.5 mounting holes.

Parts List

• C1, C2: 4.7uF 6.3V 0603 (C1608X5R0J475K080AB)
• L1: 1uH 0805 (LQM21PN1R0MC0D)
• U1: TI 5V Regulator (TPS61240DRVT)
• J1: Hirose to Zipit Connector (ST60X-36S(30))
• J2: USB Host Port (292303-1)
• J3: Amphenol FCI Micro USB Port (10118194-0001LF)
• R1: 10K ohm 0603 Resistors (Regulator Enable)
• R2, R3: 4.7k-10k ohm 0603 Resistors (I2C)
• R4: 10-100 ohm 0603 Resistor
• Q1: P Channel MOSFET (DMP2035U-7)
• C3: Tantalum 3528 Capacitor
• 1.27mm Headers Optional

Atari CX40 Joystick PCB Replacement using low profile Alps tactile smd switches (part # SKRRAAE010). The switches are “soft” and do not produce a click on the directional stick, but the spring on the fire button does cause a click noise.

https://mozzwald.com/articles/2017/12/17/pcb-lapel-pins-from-vector-images-in-diptrace

4P4C RJ11 vertical modular jack breakout board (Molex 95003). M2.5 mounting holes spaced 30mm apart. Can be panel mounted with 12mm standoffs.

Zipit Z2 Breakout v2

Parts List

• C1, C2: 4.7uF 6.3V 0603 (C1608X5R0J475K080AB)
• L1: 1uH 0805 (LQM21PN1R0MC0D)
• U1: TI 5V Regulator (TPS61240DRVT)
• J1: Hirose to Zipit Connector (ST60X-36S(30))
• J2: USB Host Port (292303-1)
• J3: Amphenol FCI Micro USB Port (10118194-0001LF)
• R1: 10K ohm 0603 Resistors (Regulator Enable)
• R2, R3: 4.7k-10k ohm 0603 Resistors (I2C)
• R4: 10-100 ohm 0603 Resistor
• Q1: P Channel MOSFET (DMP2035U-7)
• 1.27mm Headers Optional

Details

Both USB Ports are designed to be optionally broke off the middle section. Score the board with a blade on both sides down the line of holes and snap off the end. Each board when broken off can be used independently.

Main Zipit Board

This section of board contains the Hirose 36 pin connector, 1.27mm pitch headers, I2C resistors and “USB Jumpers”. The USB Jumpers allow connecting either the Micro USB (for device mode) or USB A (for host mode) port to the USB pins on the Zipit. The center pad of the jumper is connected to the Zipit. Bridge the center pad to the left or right pad with solder to set Host or Device mode.

New to v2.1 is a MOSFET that switches 3.3V ON or OFF via GPIO 51 to a through hole in the center of the board. The MOSFET is P Channel which means it is ON by default and writing a 1 to GPIO 51 will turn it off. This can be used for anything you like, but I added a tiny serial GPS module from SparkFun that fits perfectly over the USB Host port.

USB-A Board

This section of board contains a USB A Port, 3.3V to 5V boost regulator, 1.27mm pitch header and jumper pads for the regulator and host power. When attached to the main Zipit board the “Host Pwr” Jumper sets which power is supplied to the port; DCIN from the Zipit or 5V from the regulator. The “Reg Jmpr” sets the regulator to be always “ON” or by toggling the “EN"able pin high (GPIO54 or via header).

Micro USB Board

This board contains a Micro USB port and 1.27mm pitch header. The VCC pin is connected to DCIN allowing you to power the Zipit via USB cable.
