Shared Projects

Accellerometer Board L1.3 This is the companion driver board for my CylonEye (Knight Rider) project. It contains an ATTiny85 to drive the data to the LED array, and also includes an accellerometer to determine level. It is intended to be used with a RV, and is a replacement for the original equipment hitch light for many late model Grand Design Reflection 5th wheel RVs.

A full description, BoM, and project notes are available at http://www.RV-project.com/projects/cyloneye.php

MINI DSKY Sign digit light mask

This board is the mask board for the sign displays for R1, R2 and R3 on the Apollo uDSKY project. You will need 1 ea. for each display. DS_PLUS1.brd

https://github.com/b-wave/uDSKY/tree/master/uDSKY%20Hardware/DSKY_DISP

This board implements a classic Z80 microprocessor test circuit. All data pins are pulled low, causing it to execute the NOP instruction $00 repeatedly. The program counter increments and the activity on the address lines is visualized using LEDs. A slow clock signal is applied to make the address bus activity slow enough to see.

The MREQ and RD pins are also brought out to LEDs. Push buttons are available for the RESET and WAIT lines. The clock signal is generated using a 555 timer.

The board is powered by applying 5V to the 0.1" header pins. Reverse polarity protection is provided using a P-Channel MOSFET.

This board is mostly a novelty. It’s really cool to see the program counter increment on the address pin LEDs and the MREQ and RD LEDs flash. It is not possible to execute an actual program on this board, as it has exactly one byte of “memory” with the contents $00. :)

BOM

• U1: Zilog Z80 40DIP
• U2: 555 Timer 8SOIC
• Q1: Alpha & Omega AO3401A P-Channel MOSFET SOT-23 or similar
• R1-R19, R21-R22: 1k 0603
• R20: 22k 0603
• C1: 10 uF 0805
• C2, C5: 1 uF 0603
• C3-C4, C6-C7: 100 nF 0603
• RN1: 1k, 8 resistor (9 pin) SIP
• A0-A15, MREQ, RD: 0805 SMD LEDs (colors of your choice)
• RESET and WAIT switches: SPST tactile switch Through hole
• 5V header: 1x2 0.1" standard header pins

Notes

• R20, R21, and C5 set the 555 clock signal frequency. The values provided above will set a clock of approximately 32 Hz. You can use an online 555 calculator to pick different values and adjust the clock frequency as you like. In relation to the classic 555 circuit schematic: R21 on this board = R1, R20 = R2, and C5 = C.
• Brand new Z80 microprocessors are available on Digikey if you don’t have one.

Eagle Files

https://github.com/SyncChannel/Z80-Test-Circuit

Other References

http://www.z80.info/z80test0.htm

https://z80project.wordpress.com/2014/02/09/z80-test-circuit/

DCC Deccoder Hi Pwr Reg

Abs Position Detector Low Out

Abs Position Detector 4 Low Out

DCC Daughter Board

Texas Instruments CC3200MOD breakout board

Download Schematic

FPGA on a feather!

This project uses an SBM-20 Geiger-Muller tube to detect radiation hits, and then pulses a string of night lights every time there is a hit. Inspired by a “Star Jar” project I saw in which the lights and detector are all placed in a jar.

A breakout board for the AS3935 lightning sensor. Based on “Embedded Adventures” breakout board design.

Buttons for Adafruit Trinket.

A led matrix for Adafruit Trinket.

A servo controller for Adafruit Trinket.

A LCD display for Adafruit Trinket.

MSOP and SOIC 16 breakout board

Using KiCAD footprints MSOP-16-1EP_3x4mm_Pitch0.5mm and SOIC-16_3.9x9.9mm_Pitch1.27mm
