VNC2 Debug Module
author: alfishe
2 layer board of 1.18 x 0.79 inches (30.0 x 20.0 mm)
Uploaded:
January 15, 2017
Shared:
January 15, 2017
Total Price:
$4.65
See more details: https://github.com/mvvproject/ReVerSE-U16/tree/master/u16_board/modules/v2debug
See more details: https://github.com/mvvproject/ReVerSE-U16/tree/master/u16_board/modules/v2debug
F4-Brushless-Hex-Dshot-V1.zip
author: AlienFlightNG
4 layer board of 1.10 x 1.26 inches (28.0 x 32.0 mm)
Uploaded:
January 15, 2017
Shared:
January 15, 2017
Total Price:
$13.80
F4-Brushless-Quad-Dshot-V1.zip
author: AlienFlightNG
4 layer board of 1.10 x 1.26 inches (28.0 x 32.0 mm)
Uploaded:
January 15, 2017
Shared:
January 15, 2017
Total Price:
$13.80
BQ25504LoadSwitch.kicad_pcb
author: bootchk
2 layer board of 0.62 x 0.44 inches (15.8 x 11.2 mm)
Uploaded:
January 14, 2017
Shared:
January 14, 2017
Total Price:
$1.35
Energy harvester switches load to nRF52 radio. On at 2.2V, off at 1.7V, max 3.3V.
Energy harvester switches load to nRF52 radio. On at 2.2V, off at 1.7V, max 3.3V.
KBot Power rev 1
author: exuvo
2 layer board of 8.27 x 3.16 inches (210.2 x 80.2 mm)
Uploaded:
October 03, 2015
Shared:
January 14, 2017
Total Price:
$130.55
Power distribution, monitoring and charging. http://exuvo.se/project/page/kbot4
Power distribution, monitoring and charging. http://exuvo.se/project/page/kbot4
MMC5-SNES Dumper
author: MrPete1985
2 layer board of 0.96 x 1.81 inches (24.3 x 45.8 mm)
Uploaded:
December 10, 2016
Shared:
January 14, 2017
Total Price:
$8.60
NES CHR Dumper
author: MrPete1985
2 layer board of 0.96 x 1.81 inches (24.3 x 45.8 mm)
Uploaded:
December 10, 2016
Shared:
January 14, 2017
Total Price:
$8.60
NES PRG Dumper
author: MrPete1985
2 layer board of 0.96 x 1.81 inches (24.3 x 45.8 mm)
Uploaded:
November 27, 2016
Shared:
January 14, 2017
Total Price:
$8.60
SNES OTF Swap Bin
author: MrPete1985
2 layer board of 0.96 x 1.81 inches (24.3 x 45.8 mm)
Uploaded:
December 10, 2016
Shared:
January 14, 2017
Total Price:
$8.60
HALL Preamp
author: hexeguitar
2 layer board of 0.75 x 1.64 inches (19.2 x 41.7 mm)
Uploaded:
December 15, 2016
Shared:
January 14, 2017
Total Price:
$6.15
HALL sensor preamp/analog axis calibrator
HALL sensor preamp/analog axis calibrator
programmer_helper.brd
author: shlomozippel
2 layer board of 1.30 x 0.71 inches (33.0 x 18.1 mm)
Uploaded:
January 13, 2017
Shared:
January 13, 2017
Total Price:
$4.60
Ble controller Rev C SWD helper
Ble controller Rev C SWD helper
MotorThing TMCM-110
author: mkoetter
2 layer board of 1.66 x 1.66 inches (42.1 x 42.1 mm)
Uploaded:
January 13, 2017
Shared:
January 13, 2017
Total Price:
$13.75
WiFi-enabled Motion Control https://github.com/michaelkoetter/MotorThing
WiFi-enabled Motion Control https://github.com/michaelkoetter/MotorThing
QFN24 Breakout Board
author: piersfinlayson
2 layer board of 0.54 x 1.26 inches (13.6 x 32.1 mm)
Uploaded:
January 13, 2017
Shared:
January 13, 2017
Total Price:
$3.35
Designed for a CP2104 USB to UART bridge, broken out suitable for breadboard prototyping.
Note that centre pad isn't grounded, and there is no ground plane.
Designed for a CP2104 USB to UART bridge, broken out suitable for breadboard prototyping.
Note that centre pad isn't grounded, and there is no ground plane.
Cartridge.zip
author: FloppidyDingo
2 layer board of 1.71 x 1.08 inches (43.4 x 27.4 mm)
Uploaded:
January 13, 2017
Shared:
January 13, 2017
Total Price:
$9.15
BLF driver DDm-17 [rev04b][tried & tested]
author: DEL
2 layer board of 0.69 x 0.69 inches (17.4 x 17.4 mm)
Uploaded:
January 12, 2017
Shared:
January 12, 2017
Total Price:
$2.35
BLF flashlight driver, 17 mm, DD+m
Features
- 17 mm direct drive + 350 mA regulator LED driver
- No OTC - Intended for e-switch, memory-decay or no-memory firmware.
- R5 to eliminate unintentional Vcc boosting during PWM.
- R3 to eliminate unintentional flashing during mode changes. *…
Show full description
BLF flashlight driver, 17 mm, DD+m
Features
- 17 mm direct drive + 350 mA regulator LED driver
- No OTC - Intended for e-switch, memory-decay or no-memory firmware.
- R5 to eliminate unintentional Vcc boosting during PWM.
- R3 to eliminate unintentional flashing during mode changes. *…
Show full description
T31207-EDE-3010-0150-0002
author: MSU-DudleyD
2 layer board of 2.01 x 1.51 inches (51.0 x 38.2 mm)
Uploaded:
January 12, 2017
Shared:
January 12, 2017
Total Price:
$15.10
5B Instrumentation Box Fuse Card
5B Instrumentation Box Fuse Card
