Shared Projects

Snes Adapter M27C322 2 CI 74LS257

SNES Adapter M27C322

4-layer transceiver board for medical applications UCD Dart/CM 2018-07

Demonstration of MAX32660 as a motion co-processor. https://hackaday.io/project/160283-max32660-motion-co-processor

The Open Panzer Sound Card brings inexpensive, high quality, and open source sound functionality to RC models. It supports up to 32 GB of CD quality WAV files and provides 3 light outputs and a recoil servo output.

The physical board is actually made up of two components. First, an off-the-shelf PJRC Teensy 3.2 is used as the onboard processor. The Teensy is then plugged into a socket on our custom carrier board that adds a Micro SD card slot (max 32 GB), a Maxim 9768 10 watt mono amplifier, and headers for external connections.

There are two control methods available:

• By up to 5 channels of standard RC input. Each channel can be configured for multiple types of control, including switches of up to 6 positions. In this mode board settings are defined by an “ini” file which the user must include on the micro-SD memory card along with their sound files. A convenient INI Creator Utility can be downloaded which makes generating the ini file a breeze (Windows only). Instructions for using the sound card in RC mode can be found here
• Alternatively the sound card can be controlled via TTL serial by the Open Panzer TCB (Tank Control Board) or by any other microcontroller. When controlled by the TCB all configuration is handled by the TCB and its own Windows program called OP Config. Instructions for using the sound card with the TCB can be found here

Resources

• GitHub Page
• A discussion thread on the development of this card can be found on the Open Panzer Forum.
• Eagle Board and Schematic (zip)
• Printable Schematic (pdf)
• Bill of Materials - PDF - Excel

Changes in Version 3 include light and servo outputs, and mounting holes with identical spacing to the TCB.

Changes in Version 2 include a 10 watt amp (up from 2.6 watt in V1) and a reverse polarity diode on the voltage input.

Version 3, updated 7/23/2018

.

amiketo_3d/201807

buffered DC level from 10 turn pot

for connecting a DIP ZIF socket to an icestick

A small PCB that allows multiple ways to mount and connect a mini (3535) NeoPixel + capacitor. The PCBs tile - so you can just connect them edge-to-edge (the data-in and data-out pads swap from one side to the next, so data-out on one board lines up with data-in on the next board, vertically and horizontally). There are breadboard-friendly pads.

All contacts are present on both side of the boards, so you can solder either side.

Replacement STM32F103 PCB for Chinese $2 MP3 player https://hackaday.io/project/28583-portable-arm-device

Simple PCB adapter that allows USB devices to be connected to test equipment with double-banana jacks spaced ¾ inch apart (19.05 mm - measured from center to center of each individual plug) like a Bench Power Supply.

• Accepts Banana plugs with Threaded M3 Studs
• Accepts 9-pin USB Type A female connectors
• PCB traces designed to support around 2.5A when using 1oz/ft² copper thickness

Parts list

For more information, please visit the Double-banana plug to USB Type A adapter page.

Simple PCB adapter that allows USB devices to be connected to test equipment with double-banana jacks spaced ¾ inch apart (19.05 mm - measured from center to center of each individual plug) like a Bench Power Supply.

• Accepts Banana plugs with Threaded M3 Studs
• Accepts 9-pin USB Type A female connectors
• PCB traces designed to support around 2.5A when using 2oz/ft² copper thickness

A new version of this board is available with thicker copper traces and other minor improvements.

Parts list

For more information, please visit the Double-banana plug to USB Type A adapter page.

Test vehicle for ultra-low power LoRa.

BML “S7 Mini” - Spartan7 FPGA for DIP-40 or 50mil grid
