IRIO
2 layer board of 0.54 x 0.43 inches (13.7 x 10.8 mm)
Uploaded:
May 23, 2024
Shared:
July 16, 2024
Total Price:
$1.15
Low profile IR TX/RX module
Low profile IR TX/RX module
WT32-SC01-HVAC
2 layer board of 1.76 x 2.00 inches (44.8 x 50.9 mm)
Uploaded:
February 22, 2024
Shared:
February 22, 2024
Total Price:
$17.65
2nd rev for smart HVAC thermostat project
2nd rev for smart HVAC thermostat project
WaterbedSlave
2 layer board of 1.78 x 1.96 inches (45.2 x 49.8 mm)
Uploaded:
September 04, 2018
Shared:
October 15, 2018
Total Price:
$17.45
Board for a low cost Mean well AC to 3.3VDC (or 5V) and 10A relay. Made for a waterbed heater. GitHub Project
Board for a low cost Mean well AC to 3.3VDC (or 5V) and 10A relay. Made for a waterbed heater. GitHub Project
ESP181A
2 layer board of 1.58 x 0.99 inches (40.0 x 25.2 mm)
Uploaded:
October 01, 2018
Shared:
October 15, 2018
Total Price:
$7.80
Unit-T UT181A WiFi interface V2 Project on GitHub
Unit-T UT181A WiFi interface V2 Project on GitHub
ESP-HVAC
2 layer board of 1.67 x 1.98 inches (42.4 x 50.2 mm)
Uploaded:
July 02, 2018
Shared:
July 19, 2018
Total Price:
$16.50
ESP-07 HVAC WiFi Thermostat + Remote V2
Smaller, cheaper than the old one
GitHub Link
ESP-07 HVAC WiFi Thermostat + Remote V2
Smaller, cheaper than the old one
GitHub Link
