2020 LED Bar SM
author: McSpider
2 layer board of 0.50 x 0.43 inches (12.6 x 10.8 mm)
Uploaded:
August 19, 2020
Shared:
November 27, 2020
Total Price:
$1.05
Addressable led segment using 2 WS2812-2020 LED's
Use the 0.8mm PCB service to fit them into a 8mm white glass straw with an inside diameter of 5mm (commonly available from Aliexpress).
(2 Connected PCB’s, need to be broken apart.)
Addressable led segment using 2 WS2812-2020 LED's
Use the 0.8mm PCB service to fit them into a 8mm white glass straw with an inside diameter of 5mm (commonly available from Aliexpress).
(2 Connected PCB’s, need to be broken apart.)
2020 LED Bar LG
author: McSpider
2 layer board of 3.80 x 0.67 inches (96.6 x 17.1 mm)
Uploaded:
August 19, 2020
Shared:
November 27, 2020
Total Price:
$12.75
Tiny addressable led bar using 16 WS2812-2020 LED's
Use the 0.8mm PCB service to fit them into a 8mm white glass straw with an inside diameter of 5mm (commonly available from Aliexpress).
(3 Connected PCB's, need to be broken apart.)
Tiny addressable led bar using 16 WS2812-2020 LED's
Use the 0.8mm PCB service to fit them into a 8mm white glass straw with an inside diameter of 5mm (commonly available from Aliexpress).
(3 Connected PCB's, need to be broken apart.)
AA01B-S040VA1-breakout
author: XenGi
2 layer board of 2.02 x 2.31 inches (51.4 x 58.8 mm)
Uploaded:
November 27, 2020
Shared:
November 27, 2020
Total Price:
$23.35
https://gitlab.com/XenGi/tpwkbd/-/tree/AA01B-S040VA1-breakout-rev1/AA01B-S040VA1-breakout
Licensed under CERN-OHL-P v2
https://gitlab.com/XenGi/tpwkbd/-/tree/AA01B-S040VA1-breakout-rev1/AA01B-S040VA1-breakout
Licensed under CERN-OHL-P v2
UglyFace_01
author: Soggybag
2 layer board of 1.89 x 1.25 inches (48.0 x 31.8 mm)
Uploaded:
November 02, 2020
Shared:
November 27, 2020
Total Price:
$11.80
Ugly Face is a DIY raucous square wave guitar synthesizer masquerading as a fuzz pedal. Build it yourself! Build Docs
Ugly Face is a DIY raucous square wave guitar synthesizer masquerading as a fuzz pedal. Build it yourself! Build Docs
CV_LEDControl_2020-01-04
author: SpookyWoogin
2 layer board of 1.91 x 1.01 inches (48.5 x 25.7 mm)
Uploaded:
January 04, 2020
Shared:
November 26, 2020
Total Price:
$9.65
Power_Switch_RevB
author: sbernal0115
2 layer board of 2.41 x 1.91 inches (61.2 x 48.5 mm)
Uploaded:
November 26, 2020
Shared:
November 26, 2020
Total Price:
$23.00
When the voltage across shunt resistors R3 or R6 goes above 100mV, the corresponding load will be switched off/disconnected. This occurs when the current through the load exceeds 2A.
When the voltage across shunt resistors R3 or R6 goes above 100mV, the corresponding load will be switched off/disconnected. This occurs when the current through the load exceeds 2A.
GBA SP Replacement Power Switch Flex PCB
author: Helder
2 layer board of 0.67 x 0.25 inches (17.1 x 6.4 mm)
Uploaded:
November 26, 2020
Shared:
November 26, 2020
Total Price:
$0.80
Uses the following switch:
https://www.aliexpress.com/item/32853323091.html
Uses the following switch:
https://www.aliexpress.com/item/32853323091.html
GBC Replacement Power Switch Flex PCB
author: Helder
2 layer board of 0.61 x 0.25 inches (15.5 x 6.4 mm)
Uploaded:
November 26, 2020
Shared:
November 26, 2020
Total Price:
$0.75
Uses the switch from this link:
https://www.aliexpress.com/item/32951795016.html
Can NOT be used in a Game Boy Pocket
Uses the switch from this link:
https://www.aliexpress.com/item/32951795016.html
Can NOT be used in a Game Boy Pocket
GBA Power Switch Flex PCB
author: Helder
2 layer board of 0.68 x 0.30 inches (17.3 x 7.6 mm)
Uploaded:
November 26, 2020
Shared:
November 26, 2020
Total Price:
$1.00
Uses this Switch from aliexpress:
https://www.aliexpress.com/item/32951795016.html
Uses this Switch from aliexpress:
https://www.aliexpress.com/item/32951795016.html
ammy revC
author: mza
4 layer board of 0.84 x 0.73 inches (21.3 x 18.6 mm)
Uploaded:
November 25, 2020
Shared:
November 25, 2020
Total Price:
$6.10
dragonfly04 male-to-female passthrough that puts an ammeter in the circuit. Passthrough for i2c as well through two qwiic/stemma 4 pin jst/sh connectors
Schematic: <https://www.phys.hawaii.edu/~mza/PCB/misc/ammy.revC.schematic.pdf>
dragonfly04 male-to-female passthrough that puts an ammeter in the circuit. Passthrough for i2c as well through two qwiic/stemma 4 pin jst/sh connectors
Schematic: <https://www.phys.hawaii.edu/~mza/PCB/misc/ammy.revC.schematic.pdf>
RC3 Fairy Dust Pin
author: flummer
2 layer board of 0.95 x 2.11 inches (24.1 x 53.6 mm)
Uploaded:
November 24, 2020
Shared:
November 25, 2020
Total Price:
$10.00
This is a small PCB pin badge, heavily inspired by the RC3 styleguide. It's designed to be small, easy to assemble and hopefully many will manage to get some before the event, and be able to share a little bit of physical #badge…
Show full description
This is a small PCB pin badge, heavily inspired by the RC3 styleguide. It's designed to be small, easy to assemble and hopefully many will manage to get some before the event, and be able to share a little bit of physical #badge…
Show full description
