Hall Latch, 3.5V to 24V, Melexis US1881

Two of these will be able to make a quadrature encoder with North and South facing magnets. The US1881, us1881-datasheet-melexis.pdf, is a latching device requiring the opposite pole to unlatch/latch. R1 (SMT 1206) is 10K and must be rated for the voltage you use. These do work at 3.3 volts.

Note (180314): This board has been tested and found to be working according to expectations! Correction of some minor design flaws is underway! A new but untested design is available here: https://oshpark.com/shared_projects/uIL9j2Ex

The quick and dirty mockup code is available here: https://github.com/overengen/Pedestrian_Crossing_for_the_RPi

Warning! This board hasn’t been tested yet, but the mock-up did work as intended but there might still be issues that needs to be addressed such as the “be or not to be” capacitor placed over the buzzer. And then there is this tiny detail about the order of LEDs and resistors… Mounting holes are missing, and the board might be ½ mm to short. Watch out for future revisions!

This is my first attempt to design a PCB for the Raspberry Pi. It’s a dead simple design and supposed to fit on top of a Raspberry Pi (65x56.5mm). With a bit of coding the Raspberry Pi should be able to control all the LEDs, the buzzer and read the push button. My intention is to use this as a base for a coding project at school. Pin numbers (connecting to the switch, the buzzer and the LEDs) are written on the surface of the PCB as a reference in order to make coding a bit easier.

BOM:

3 x 10mm LEDs (red, yellow, green).

2 x 5mm LEDs (red, green).

1 x 3mm LED (yellow or white).

1 x Switch 4pins, 6mm.

1 x Buzzer

6 x Resistors (~50 Ohm)

1 x Connector (20x2)

Warning! This board hasen’t been tested yet, there might still be issues that needs to be addressed. Watch out for future revisions!

Note (180314): A previous and tested version of this design is available here: https://oshpark.com/shared_projects/wrF9XJDk

The quick and dirty mockup code is available here: https://github.com/overengen/Pedestrian_Crossing_for_the_RPi

The pin layout has been changed in this later revision of the PCB, but this is easily corrected in the program by swapping out a few numbers accordingly.

Update: v0.5 - Adjusted position af the mounting holes and dimensions around the corners that was slightly of and smaller in arc.

Update: v0.4 - Rearranged som of the graphic, redesigned the wiring and pinout to make them follow a more logical order and easier to use while programing.

GPIO Reference:

P20 - Red 10mm

P21 - Yellow 10mm

P22 - Green 10mm

P23 - Red 5mm

P24 - Green 5mm

P25 - White 3mm

P26 - Switch

P27 - Buzzer

This is my first attempt to design a PCB for the Raspberry Pi. It’s a dead simple design and supposed to fit on top of a Raspberry Pi (65x56.5mm). With a bit of coding the Raspberry Pi should be able to control all the LEDs, the buzzer and read the push button. My intention is to use this as a base for a coding project at school. Pin numbers (connecting to the switch, the buzzer and the LEDs) are written on the surface of the PCB as a reference in order to make coding a bit easier.

BOM:

3 x 10mm LEDs (red, yellow, green).

2 x 5mm LEDs (red, green).

1 x 3mm LED (yellow or white).

1 x Switch 4pins, 6mm.

1 x Buzzer

6 x Resistors (~50 Ohm)

1 x Connector (20x2)

attiny85 Programmer with ISP usbtiny programmer

Blog post - https://facelesstech.wordpress.com/2018/03/17/attiny85-backpack-programmer-header/ Youtube - https://youtu.be/_xBqEfxCav8 Github board files - https://github.com/facelessloser/attiny_85_programmer_header

50mil castelation ICSP jig for Northpaw Nano rev G

• ATMEGA328P-MU (or equiv 32-pin ATMEGA 328/168/etc in MLF footprint)
• MAX4822 (there is no alternative - not even in a different footprint or functionality - this is THE ONLY 3v 8channel PWM/PSAVE with kickback - let me know if you find another (other than MC33996, which is “technically” 5v - see my “Northpaw Mini” versions instead)
• MCP1700T-3002E/TT (or any pin-compatible 200mA 200mV sot-23 LDO)
• 0805 MLCC ceramic capacitors - 0.1uF, 0.22uF, 1uF, 10uF (x2)
• 0805 resistors - 10k ohm (x2) - (for voltage divider. use other values for better voltage granularity)
• LSM303DLHC (magnetometer/accelerometer - LGA)
• 8x 100mA motors
• Ribbon cable
• JST-PH connection to Li-Po/Li-Ion battery (or other 3.0v-6.0v battery pack)
• Optional 0805 LED & 0805 resistor for it (choose for however bright you want, e.g. 1k ohm)

All chips rated 2.3v-3.6v (lsm303 can go lower; and the rest are rated up to 5.5v - and all 85 deg C) lsm303: vdd 2.16v-3.6v; max4822: vcc 2.3v-5.5v; 328p: 2.7v-5.5v@8MHz (1.8v@4MHz)

Programming ICSP on custom pinout 50mil pitch castellation.

“Flora-compatible” mounting holes (random holes near edges, probably sewable)

Active power consumption: 100mA-50mA single motor; 6mA atmega; 1.5mA max4822; 150uA lsm303 (that can’t be right); sleep power consumption (after battery level low): 150uA (typ)/300uA(max) into MAX4822; 8uA into motors (leakage); 1uA into atmega (power-down with PRR off, WDT off, & BOD off); 1uA into lsm303 (so they say) so ~0.2mA after flat battery - so don’t leave it plugged in for weeks after shutdown or it will destroy the battery.

MLX10407 breakout board - essentially implements the example schematic in the datasheet. The specced crystal is the ACH-8.000MHZ-EK from ABRACON, but any 8MHz crystal should work.

Micromouse V2.0 PCB

2 layer board of 1.44 x 0.75 inches (36.5 x 19.1mm) 3 boards will cost $5.35

Hassle free 3D printing using ESP8266 : This LUA code and Adapter for ESP8266 provides wireless networking for RepRap 3D printers. No wired connection is required during the print job - just stream your Gcode up to the ESP module’s IP address.

From the day of its launch, the ‘ESP8266’ is under the spotlight of many makers, electronic enthusiasts and hackers. The Creatorbot team was quite impressed with the ESP module and we were curious to see if we could interface this module with our 3D printer. When we decided to do it, I started researching on the tool chain for developing on the ESP module and found that LUA API from NodeMcu would be a good start. The code quality if definitely not perfect but it works fine. To make it easy to use I have develeopped ESP8266 adapter for RAMPS 3D printer shield using Eagle CAD.

Features:

WiFi enabled G-Code streaming.
Remote control and monitor your printer.
Automatically displays the IP address of ESP module on your printer LCD.
Same adapter can also be used to connect HC-05 / HC0-06 Bluetooth module to RAMPS 3D printer shield.

3D-Printing-ESP8266

This is an all in one board instead of having to use the regulator module, and allows direct plugin to the ramps board

see bein

RFid reader with BLE

A simple maze game based on an ATtiny85 that you navigate with four pushbuttons. The available paths in each direction are shown by four LEDs. A lit LED means that your way is blocked by a wall, and a speaker beeps if you try to move in that direction. When you get to the goal a tune confirms you’ve succeeded.

See http://www.technoblogy.com/show?20UO.

CUI PYB20-Q48-S51 48VDC to 5VDC Isolated converter

for EEPROM 28C256

All needed files are availables here –> https://drive.google.com/open?id=1md9C5Au9TwCAe9fqd97qvTXGewMKVrLg

Suzuki RV90 Electronic Blinker Relay (Tested on a 1977)

• Suitable For 6V Hi-Side systems
• Work on any load up to 10Amps
• Steady frequency of 1.5Hz
• Overcurrent Protection
• No more mechanical parts

For any help, you can contact me at [email protected]
