TheLittleEngineers.org-27C512E-TO-2532S-V1R1.20.APRIL.2019-01.JUNE.2019(EAGLE). TheLittleEngineers.org-27C512E-TO-2532S-V1R1.20.APRIL.2019 27C512 E.P.R.O.M. TO TMS2532 SOCKET CONVERTER. © 20 April 2019 and 01 June 2019 by: Robert Allen Turner http://www.TheLittleEngineers.org/ https://github.com/TheLittleEngineers

This product is intended to allow a 27512 or 27C512 EPROM to be placed into a TMS2532 EPROM socket. The 27512 is divided into 16 banks of 4Kbytes via the four jumpers at the bottom of the socket.

Released under a Creative Commons Attribution-ShareAlike 4.0 International (CC BY-SA 4.0) License, 01 June 2019 In Memory of my Father, Robert Embry Turner, 1945 - 2019. Rest In Peace. I LOVE YOU DAD!

Archive name: “TheLittleEngineers.org-27C512E-TO-2532S-V1R1.20.APRIL.2019”

This is an update to the “TheLittleEngineers.org-27C512E-TO-2532S-V1R0.20.APRIL.2019” repository which resides at this url: https://github.com/TheLittleEngineers/27C512E-TO-2532S-V1R0 This update was made due to the fact that I was not very pleased with the initial Printed Circuit Boards that resulted from the original design. Although functional, the production of the Printed Circuit Boards was inconsistent between different manufacturers. This was due to a problem in the dimension layer of the original design and so I have created this new design to eliminate the inconsistencies.

This version should provide much better results.

Please note: This is derived from an original design by “Little” John Eric and/or his father “Big” John Robert (J.R.) by “Uncle” Robert Allen. It should be thoroughly scrutinized and verified prior to actual use of any kind. DISCLAIMER: The following article is provided for informational purposes only. Any attempt to modify your computer without the proper skills to do so may void your computer. Any attempt to modify your computer without unplugging it first may void you. This Information is provided “as-is” with no guarantee of fitness for any purpose, either explicit or implied. We disclaim any and all responsibility for losses incurred through the use of this information. By using this information, you are deemed to have accepted these conditions of use, and you agree NOT to sue us. CLARIFICATION: The above disclaimer states as plainly as possible that if you decide to make use of any of the information contained within this document that you do so at your own risk. Designing hardware for the CoCo (ColorComputer) and other vintage hardware is a hobby of ours and is not motivated by any desire of profits. As this is a not for profit venture, obviously we can’t afford not to disclaim the use of this information.

The GitHub home of this project is available at the following url: https://github.com/TheLittleEngineers/27C512E-TO-2532S-V1R1.20.APRIL.2019

This design is available at OSHPark with the following urls: https://oshpark.com/shared_projects/JmUiHyi1 (EAGLE .brd) https://oshpark.com/shared_projects/4RvjjYdM (KiCAD .kicad_pcb) Note that the KiCAD version has been imported using the EAGLE import function of the Version 5.x of KiCAD. As such, it may be potentially problematic.
