Ergonomics and Sports Tracker

STM32L432 host, 10 DoF sensors, ZOE M8Q concurrent GNSS, 16 MByte SPI flash memory for data logging, ESP32 for streaming data via wifi/BLE/ESPNOW. Designed to mount into a Hammond 1551QTBU box.

PTN78020WAH Board

Interfacing a PNP Capacitive sensor to a 3d Printer

Universal Multi-Out PCB for Nintendo SNES, N64 (RGB-Modded) and other Nintendo Consoles with Multi-Out Connector.

Link to Circuit-Board VSAB Thread

• removed series resistors
• added RC for Sync
• added parallel resistors

Vertical SCART Adapter Board

Based on VSAB Plain

• added 75R termination resistors to R, G, B, S

Auto light

Attiny10 & APDS-9930 based automatic light/switch

https://github.com/N-Storm/autolight

https://easyeda.com/NStorm/autolight-board

This project utilizes small ATtiny10 mcu to work with APDS-9930 ambient light (AL) and proximity I2C sensor. This is used for automatic “smart” light in a drawer. Once the drawer are open the APDS-9930 will notice proximity change and trigger a preset interrupt and MCU will come from sleep to check if AL level are below set (i.e. it’s dark around). If the set condition for AL level will be met, it will enable HIGH level on PB3 pin. Which is connected to a MOSFET or any other switch to enable LED light.

Reset shares same PB3 pin so it must be disabled via fuses. You will have to apply +12V to PB3/RESET pin to reprogram attiny10 after flashing RSTDISBL fuse.

The PB2 port are used as INT0 for sensor interrupts to wake MCU from sleep on proximity change event.

Building

Fetch the latest trunk:

git clone https://github.com/N-Storm/autolight && cd autolight

Then tweak some settings in autolight.h if required. They are commented. After that do a:

make && make flash && make fuse.

:warning: After you do a make fuse step, you won’t be able to program MCU again without applying +12V to RESET pin (make sure it’s not connected to your programmer hardware :warning:

Alternatively you can use pre-built binaries with the default settings from releases section.

Connecting

PB0 ↔ SDA<br /> PB1 ↔ SCL<br /> PB2 ↔ INT<br />

PB3 are the module digital output, with logic LOW when light should be turned off and HIGH when it should be on. Suited for connecting to an N-channel FET driving the LED light.

Please be aware that the APDS-9930 module requires 2.5 – 3.6 V for it’s operation on Vdd+Vbatt (IR LED power). I recommend to use a 3.3V LDO for powering both MCU & APDS-9930.

Schematics & board are available on EasyEDA: https://easyeda.com/NStorm/autolight-board

:warning: This board has two places for LDOs - U3 & U4. Solder only one of them! :warning:

They replace each other. The board are made so they could replace each other. Alternatively edit board/schematics to replace them with your favorite LDO.

This project utilizes software I2C library by eXtreme Electronics, India. www.eXtremeElectronics.co.in

Minimal breakout board for Silicon Labs SI705x/SI702x/Si7006 I2C temperature / temperature + humidity sensors.

This board does not includes any sort of voltage regulator. Make sure to supply correct Vcc (1.9 to 3.6 V) for this board. Connecting directly to 5V MCU (like Arduino without 3.3 V voltage regulators) will burn this sensor. This is a minimal circuit from “Typical Application Circuit” section from the datasheet.

Parts list (BOM):

R1-R2: Resistor, 10 k, ±5%, 1/16 W, 0603 C1: Capacitor, 0.1 μF, 16 V, X7R, 0603 U1: Si705x/702x/7006 sensor, DFN6.

Tested to work with Si7051 high accuracy temperature sensor, reading data with Arduino.

Got the idea from Brian Lough (https://blough.ie/bloughr).

Designed for use with After Dark service.

KiCad board files

SVG design by Shawn Hymel

IEEE 1284 parallel port for Raspberry Pi

https://github.com/worlickwerx/pi-parport

This board was developed by the VoronDesign community.

Original and uptodate version here: https://github.com/VoronDesign/Voron-Hardware/tree/master/Microswitch_Endstop

It’s a microswitch endstop board for X and Y axes. Designed with Omron D2F-L switches in mind, however, others might work as well. You can use whatever connector you want. It is wire compatible with the hall effect board. The VIN pin is not used. If you have no intention of switching to the hall effect board, you can run 3 wires instead of 4 as it shares a common ground.

You will need a different stl for the pod. Check https://github.com/VoronDesign/VoronUsers for the microswitch pcb pod.

Adapter for CP2104 USB 2.0 to TTL converter to auto program of plain ESP8266 modules. https://github.com/thomo/espprogrammer
