BT Data Link ver2
author: kocis
2 layer board of 1.58 x 3.15 inches (40.1 x 80.1 mm)
Uploaded:
May 23, 2015
Shared:
August 27, 2015
Total Price:
$24.90
Bluetooth - UHF serial data link.
Simple connection bluetooth module HC-06 with the UHF radio module HM-TRP-868. I use this for communication between ground station and my plane for wireless gps tracking.
The first attempt at covers.
Show full description
Bluetooth - UHF serial data link.
Simple connection bluetooth module HC-06 with the UHF radio module HM-TRP-868. I use this for communication between ground station and my plane for wireless gps tracking.
The first attempt at covers.
SNES LEDS LOGO PIC v1.0
author: EUYIN
2 layer board of 0.64 x 1.03 inches (16.2 x 26.1 mm)
Uploaded:
August 25, 2015
Shared:
August 26, 2015
Total Price:
$3.25
This board is the control module of a retroiluminated led board for the SNES logo. The project is based on the BORTI4938's project https://oshpark.com/shared_projects/y0B9ys9V but controled via a PIC12F1840.
This board is the control module of a retroiluminated led board for the SNES logo. The project is based on the BORTI4938's project https://oshpark.com/shared_projects/y0B9ys9V but controled via a PIC12F1840.
ESP8266-01 minimal node v1
author: ajitam
2 layer board of 0.67 x 0.86 inches (16.9 x 21.8 mm)
Uploaded:
August 26, 2015
Shared:
August 26, 2015
Total Price:
$2.85
Circuit for minimal setup of ESP8266-01 with 3.3 regulator and P0/P2 exposed
Circuit for minimal setup of ESP8266-01 with 3.3 regulator and P0/P2 exposed
15214^0
2 layer board of 0.95 x 0.48 inches (24.1 x 12.1 mm)
Uploaded:
August 05, 2015
Shared:
August 26, 2015
Total Price:
$2.25
OneShot
Simple Monostable Multivibrator Circuit that functions as a one shot that ignores the switch during activation time, e.g. further switch closures do not reset the timing circuit. .
OneShot
Simple Monostable Multivibrator Circuit that functions as a one shot that ignores the switch during activation time, e.g. further switch closures do not reset the timing circuit. .
FTDI to ESP8266 adapter
author: Skriglitz
2 layer board of 0.66 x 0.85 inches (16.8 x 21.6 mm)
Uploaded:
August 26, 2015
Shared:
August 26, 2015
Total Price:
$2.80
3.3v FTDI serial to ESP8266 adapter with GPIO0 jumper to ground
3.3v FTDI serial to ESP8266 adapter with GPIO0 jumper to ground
HV Rescue 26
author: KO4XL
2 layer board of 1.24 x 1.13 inches (31.5 x 28.6 mm)
Uploaded:
August 25, 2015
Shared:
August 25, 2015
Total Price:
$6.95
Adapts MightyOhm HV Rescue Shield to ATtiny26/261/461/861. Plugs into ATtiny2013 socket on shield.
Adapts MightyOhm HV Rescue Shield to ATtiny26/261/461/861. Plugs into ATtiny2013 socket on shield.
GHPi Board
author: d33zdotcom
2 layer board of 1.76 x 0.97 inches (44.7 x 24.7 mm)
Uploaded:
February 23, 2015
Shared:
August 25, 2015
Total Price:
$8.50
it works!
http://www.d33z.com/2014/12/first-pcb-woot.html
it works!
http://www.d33z.com/2014/12/first-pcb-woot.html
PC10 Sec Replacement 2
author: 2600
2 layer board of 0.41 x 0.41 inches (10.4 x 10.4 mm)
Uploaded:
August 25, 2015
Shared:
August 25, 2015
Total Price:
$0.80
Replaces Security Chip on PC Carts. Requires new Instruction ROM.
Replaces Security Chip on PC Carts. Requires new Instruction ROM.
DigiWire rev 2a
author: KO4XL
2 layer board of 1.75 x 0.75 inches (44.5 x 19.0 mm)
Uploaded:
July 25, 2015
Shared:
August 25, 2015
Total Price:
$6.55
Combines best of DigiSpark and LittleWire in an all thru-hole board.
Combines best of DigiSpark and LittleWire in an all thru-hole board.
DigiWire rev 5
author: KO4XL
2 layer board of 1.64 x 0.75 inches (41.7 x 19.0 mm)
Uploaded:
July 25, 2015
Shared:
August 25, 2015
Total Price:
$6.10
Best of DigiSpark and LittleWire together with no surface mount parts!
Best of DigiSpark and LittleWire together with no surface mount parts!
