Attiny85 2I/3O Transistor Output PCB.

Power and signal distribution board for use with Raver Lights. See https://github.com/nebrius/azure-led-booth/ for more info.

Power/signal splitter board for use with Raver Lights. See https://github.com/nebrius/azure-led-booth/ for more info.

Click here for the .STL files that go with this board: https://sudomod.com/forum/viewtopic.php?f=58&t=7761&p=72677#p72677

Click here for the .STL files for this board https://sudomod.com/forum/viewtopic.php?f=58&t=7761&p=72677#p72677

Zener avalanche random generator, 1000 bits/sec, 3.3V-5V. Uses PIC16F1615.

My second attempt at a breadboard adapter for using Thonkiconn-style 3.5mm mono jacks. These jacks can plug directly into a breadboard but they’re not very secure, so a breadboard adapter with more pins is a nice way to secure it. Also I tend to forget which pin is which when using other adapters that I’ve found.

This is based on little-scale’s similar board but I wanted a smaller board and labels for the connections.

There is a project page on github for this with kicad source files, pdf schematics, gerbers, etc. It’s for the newer version (V3) but is nearly identical.

BOM:

• 2 Thonkiconn jacks (QingPu WQP-PJ398SM or WQP-PJ301M-12, or compatible)
• 2 2x3 pin male headers

Changes from v2c to v2d:

• Everything is a little closer together.
• The board’s edges are a lot closer to everything.
• Because of those other changes, the board is a little smaller/cheaper.

Things to change/fix in future versions:

• Make the traces wider – I’m pretty sure they’re OK as-is, but why not make them wider since I have the room. (fixed in V3)
• Move the traces to the bottom of the board – Again, it’s OK enough as-is, but if they were on the bottom, then the labels wouldn’t be on top of them, warping the letters a little. (fixed in V3)

Render of the newer version:

(which is almost identical to this version)

Update 2020/04/17: This board has been tested and works great.

[NOTE: This board hasn’t been tested yet. It’s simple enough that I’m fairly certain it’s OK, but in case it’s not, this is why. After I test it, I’ll remove this note.]

There are already some other RPi Zero audio output pcbs available, but this one was designed specifically with several goals in mind:

• mono
• through hole
• fits inside my RPi Zero case
• uses a PJ302M jack to mount it to the case
• decently documented

It’s based on a circuit from tinkernut though I’m not sure if they originated it (it’s just a passive filter, after all). See that tinkernut page for more info about setting up the RPi to work with it. And if that page ever disappears, feel free to google for something like “rpi zero pwm audio” since there are many articles about how to set that up. I used through-hole components because I didn’t have all the right parts in SMD. There are no mounting holes because it’s intended to be panel-mounted via the jack.

There is a project page on github for this with kicad source files, pdf schematics, gerbers, etc.

BOM:

• R1 = 270R
• R2 = 150R
• C1 = 10uF electrolytic, 2.5mm lead spacing
• C2 = 33nF ceramic, 5mm lead spacing (tinkernut’s page says “0.33uF” but other similar schematics say 33nF)
• J1 = PJ302M 3.5mm mono jack
• J2 = 1x2 pin header (I use right angle)

The lead spacing for the capacitors is not a strict requirement, since you can always bend the leads in or out a bit if you’re close. When shopping for the electrolytic cap, be aware of its size, especially if you’re going to be putting this in a tight space like I am.

This is a shield that fits on top of an Adafruit Huzzah Feather to facilitate it being neatly connected to a Mitsubishi Heatpump.

Parts required:

1 x Adafruit Huzzah Feather: https://www.adafruit.com/product/3046

2 x 10k resistors: https://uk.rs-online.com/web/p/through-hole-fixed-resistors/7077745/

1 x JST PA header: https://uk.rs-online.com/web/p/pcb-headers/5128490/

4 x JST PA jumper wires: https://www.digikey.co.uk/product-detail/en/jst-sales-america-inc/APAPA22K305/455-3086-ND/6009462

2 x JST female connectors PAP-05V-S: https://uk.rs-online.com/web/p/pcb-connector-housings/4766798/

If you want to be able to switch between the hardware serial and using GPIO pins 12/14 (software serial), you will need jumpers as below. Otherwise you can just solder the pins together.

2 x jumper headers: https://uk.rs-online.com/web/p/pcb-headers/4958470/

2 x jumpers: https://uk.rs-online.com/web/p/jumpers-shunts/6742397/

For more info see here: https://nicegear.nz/blog/hacking-a-mitsubishi-heat-pump-air-conditioner/

Get the software here: https://github.com/SwiCago/HeatPump

PROVIDED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.

Breakout board for SOT23 voltage references (series type), most of them adhere to this pinout. For more information see github

MCP1702 in SOT23 housing, breakout board, for more information check github.

CoCoDragon-32K-EPROM-Cartridge-CC1-32KEC-0001.1 is the 32K Version of the CoCoDragon-8K-EPROM-Cartridge-CC1-8KEC-0001.1 - It is a 32K EPROM Cartridge for the Tandy Radio Shack TRS-80 Color Computer 1, 2, 3 and Dragon Data Dragon computers. This was one of the very first things that my nephew created when he was teaching himself electronics and computer design - it works, but could be better. He made and sold about 30 or so of these almost ten years ago. The design was meant to be as small as possible so as to fit entirely inside the cartridge Program Pak port and was useful for DriveWire or CoCoNet. It uses a 27256 EPROM. Updated to version 0001.1 on 5 May 2019 by “Ankle” Bob and released under a Creative Commons Attribution-ShareAlike 4.0 International (CC BY-SA 4.0) License [https://creativecommons.org/licenses/by-sa/4.0/] - there is definitely a lot of room for improvement and “Little John” made many improved versions which will be shared as I get more time to do so. There is a github page for this project here: https://github.com/TheLittleEngineers/CoCoDragon-32K-EPROM-Cartridge-CC1-32KEC-0001.1 and an OSHpark page here: https://oshpark.com/shared_projects/mqju7EpZ

Notes: The CoCo 1, 2 and Dragon can only access the first 16K. The CoCo 3 can access the entire 32K, minus the 0xFFnn I/O and Vector page. Many other similar (but much improved) cartridges are forthcoming. There are much better designs in my possession and I intend to post them all, in no particular order.

• PLEASE NOTE: THIS VERSION HAS NOT YET BEEN TESTED.

Please note: This is derived from an original design by “Little” John Eric and/or his father “Big” John Robert (J.R.) by “Uncle” Robert Allen. It should be thoroughly scrutinized and verified prior to actual use of any kind. DISCLAIMER: The following article is provided for informational purposes only. Any attempt to modify your computer without the proper skills to do so may void your computer. Any attempt to modify your computer without unplugging it first may void you. This Information is provided “as-is” with no guarantee of fitness for any purpose, either explicit or implied. We disclaim any and all responsibility for losses incurred through the use of this information. By using this information, you are deemed to have accepted these conditions of use, and you agree NOT to sue us. CLARIFICATION: The above disclaimer states as plainly as possible that if you decide to make use of any of the information contained within this document that you do so at your own risk. Designing hardware for the CoCo (ColorComputer) and other vintage hardware is a hobby of ours and is not motivated by any desire of profits. As this is a not for profit venture, obviously we can’t afford not to disclaim the use of this information.

Adds WiFi capability to Solar Powered Gates. Basically supports 4 switch inputs and 4 switch outputs. Outputs have read-back which is used to sense external switch closures. This board looks like an Arduino MKR1000 WiFi board to the Arduino IDE so development is easy. It fits a Hammond Manufacturing 1554E enclosure and was designed with KiCad. Check Github for the KiCad design files and code. Rev 1.1 updated to KiCad 5.1 libraries.

Adds WiFi capability to Aerobic Septic Systems. Supports an external Solid-State-Relay for effluent pump control. Has inputs for 3 alarm switch closures: air pump alarm, high water float alarm, and bleach level alarm. This board looks like an Arduino MKR1000 WiFi board to the Arduino IDE so development is easy. It was designed with KiCad. Check Github for the KiCad design files and code. Rev 1.1 updated to KiCad 5.1 libraries.

Use Thonkiconn jacks.
