Shared Projects

An adapter board for RUDY - the Random USB device - to use it as an USBasp programmer. Adds the indicator LEDs as well as a 6-pin and 10-pin ISP header along with a dock for RUDY itself.

• RUDY
• USBasp adapter board design files
• USBasp firmware adjusted for RUDY

RUDY - the Random USB Device - is a fully open source, breadboard friendly, Arduino-compatible(ish) ATmega328 development board with optional USB functionality via the V-USB library.

It’s the successor of the ATmegaX8 Protoboard and features an ISP header (smaller 6-pin this time), all the circuitry for V-USB, and is either powered straight from the programmer or the USB port - either directly at 5.0V or via a 3.3V voltage regulator.

• Official website
• Hackaday.io project page
• GitHub repository

Breakout board for connector on a BlackBerry Q10 keyboard, as posted by eevblog user JoeN: https://www.eevblog.com/forum/beginners/how-to-connect-to-a-very-very-challanging-blackberry-q10-keyboard-connector/msg1220531/#msg1220531

This is not my design, use at your own risk, etc.

[Doesn’t blow up! but still untested on an amiga or in a DB25 shell] If you order a set of these, please consider buying me a coffee and supporting open source creators Should fit inside a standard DB25 shell (compared to a 3D model. not actually tested for fit yet) deets: Github project

Just like my original ESP-01 Tamer (see my other projects), but with a micro USB socket instead of the USB-A plug.

This little board makes it super easy to use the ESP-8266 ESP-01 board in the Arduino environment. The following features are provided:

• CH340G based USB serial interface
• Auto control of RST/IO0 for downloading (uses DTR and RTS like NodeMCU, Wemos mini, etc.)
• Onboard 3.3v regulator
• Bidirectional 5v/3.3v logic level conversion on Rx, Tx, IO0, IO2
• Breadboard-friendly breakout of all essential pins

Parts list:
R1-R9 - 10K 0805 size
R10,R11 - 470 ohm 0805 size
R12,R13 - 10K 0805 size
Y1 - 12mhz SMD-3 ceramic resonator
IC1 - LD117AS33TR SOT223 3.3v 3-terminal regulator
IC2 - CH340G USB to serial interface
D1 - B5819W-TP SOD123 Schottky diode
C1,C4 - 100nf 0805 size
C2,C3 - 10uf 0805 size
Q1-Q4 - 2N7002 SOT23
Q5,Q6 - S8050 SOT23
JP1 - 2x4 0.1" thru-hole female header
JP2,JP3 - 1x4 0.1" thru-hole male header
JP4 - 1x1 0.1" thru-hole male header (optional, in case you need uUSB ID pin)
J1 - Hirose ZX62D-B-5PA8 micro USB female surface mount connector

Eagle files on Github: https://github.com/bratoff/ESP-01-Tamer

A voltage divider and low pass filter with the option to apply a ~10-500 kHz frequency on the DC endcaps of an ion trap

Second version… should actually fit the power module…

Pre-Amp to go with the Mixer project

Two Rig, Two Stereo Mixer

just a rough as guts throw together for my own personal use. This was the cheapest route to convert a male SCART head across to BNC for PVM input. Just route an off cut/ cheap piece of cable through, solder down and add screw down BNC terminals for RGBs, shielded audio and RCA connectors or a cut up RCA cable for audio.

QUBIK Pocketqube satellite main communications board. Based on PQ9ISH standard. Repository here https://gitlab.com/librespacefoundation/pq9ish/pq9ish-comms-vu-hw/

qubik tag

[UNTESTED] Should fit inside a standard DB25 shell/housing [NO IT WON’T use This one] deets: Github project

For details see: https://sites.google.com/site/wayneholder/the-useless-machine-and-the-sonic-grenade

Please visit the MSP432 feather board GitHub repo for additional resources, parts list, and other technical resources.

now with JTAG!

GitHub: https://github.com/skerr92/msp432-feather
