Description

minimal breakout board for ESP8266 chip to seeed grove header.

features

• RX/TX lines broken out to seeed grove header
• 100mil header pins for Power (external power)

• 100mil header for Firmware Update (bridges GND to GPIO0)

• no hardware reset, software only

SMD 555 PWM Board Box Modders

LulfroBrushed_v3

Description

Breakout board for ESP8266 to Seeed Grove Headers.

Features

• hardware reset button ( for when AT+RST command fails)
• firmware update mode jumper
• Power pins broken out to jumper

Simple breakout board for the ESP8266 chip to provide wifi capability to the Teensy 3.1. Designed to take power from VIN via USB or LiPo battery and convert to 3V3 with a TLV7333 300 mA voltage regulator. Also on board is a Macronix 4 Mbit MX254006E SPI Flash memory chip. Small rgb led indicates power on, pcb antenna matched to 2.4 GHz. Can use either 26 or 40 MHz Seiko Epson crystal. The board has the same eight pins as the cheap Chinese modules as a first cut to see how hard it is to add wifi to Teensy 3.1 projects. The board is designed to solder directly on top of the Teensy just above the USB plug.

Breakout board for ATTinyX8 family of MCUs

Updated v1.1 Breadboard adapter for MxChip EMW3162 Wifi module. This is currently untested(my boards have been ordered), feedback is appreciated at spider[at]anibit[dot]com.

amiketo/2015-04

amiketo usb

amiketo oled (128x64)

The latest version of this documentation and of the Flashlight project is available at https://github.com/stockton-flashlight/flashlight or https://git.flirble.org/flashlight/flashlight.

Flashlight design © 2015 Chris Luke. Flashlight documentation © 2015 Chris Luke.

This project is licensed with the CERN Open Hardware Licence v1.2.

You may redistribute and modify this project under the terms of the CERN OHL v.1.2. (http://ohwr.org/cernohl). This project is distributed WITHOUT ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING OF MERCHANTABILITY, SATISFACTORY QUALITY AND FITNESS FOR A PARTICULAR PURPOSE. Please see the CERN OHL v.1.2 for applicable Conditions.

The latest version of this documentation and of the Flashlight project is available at https://github.com/stockton-flashlight/flashlight or https://git.flirble.org/flashlight/flashlight.

Flashlight design © 2015 Chris Luke. Flashlight documentation © 2015 Chris Luke.

This project is licensed with the CERN Open Hardware Licence v1.2.

You may redistribute and modify this project under the terms of the CERN OHL v.1.2. (http://ohwr.org/cernohl). This project is distributed WITHOUT ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING OF MERCHANTABILITY, SATISFACTORY QUALITY AND FITNESS FOR A PARTICULAR PURPOSE. Please see the CERN OHL v.1.2 for applicable Conditions.

Based on MMMonkey/MKL design. http://imgur.com/7BOnnDs

Guitar Pedal

Quantracker Air OSD V2.1

Version 2.1 of the quantracker OSD board. Full Graphics OSD. Hardware floating point for great performance. Many peripheral functions available (I2C, SPI, SP PWM , ADC Capture Compare etc) on the breakout pins. (See the stm32f4 datasheet for more details) With STM32F4 on board The OSD is quite capable of being expanded intoto a full Flight controller with OSD. Here is a video of the maiden flight. Flight Video Schematics Bill of materials Source code YouTube Docs

• Discussion on DIYDrones

24 bit ADC, TI ADS1258

16 channels, 125k sps.

Includes an extra 8 GPIO, I2C EEPROM and serial console. On board regulators for digital and analog supplies. Main parts: ADS1258, LTC6655, 24LC32A.

Placa para compatibilizar o barramento dos primeiros CP200 com o do TK85.

PIC micro controlling a multi-channel, 24 bit ADC, displaying voltage and current on an LCD. As used in my dual channel power supply: http://stevenmerrifield.com/powersupply/index.html

Interface for linear regulator as used on my dual channel power supply: http://stevenmerrifield.com/powersupply/index.html

400Hz oscillator for use as a reference supply with mechanical synchro transmitters.

Input: 28V DC, Output: 26V AC 400Hz
