FT231X breakout V1.0
author: DeuxVis
2 layer board of 1.47 x 0.87 inches (37.2 x 22.0 mm)
Uploaded:
January 19, 2017
Shared:
January 19, 2017
Total Price:
$6.30
A breakout board for all of the FTDI FT231X pins. Usefull for prototyping with that chip. Source on GitHub.
A breakout board for all of the FTDI FT231X pins. Usefull for prototyping with that chip. Source on GitHub.
9265FilterB.brd
author: Mike-Eng47
2 layer board of 1.56 x 2.12 inches (39.7 x 53.9 mm)
Uploaded:
January 19, 2017
Shared:
January 19, 2017
Total Price:
$16.55
NI 9265 Pi Filter. Uses Phoenix Contact 1786488 and 1757323 connectors and 1206 L's and C's
NI 9265 Pi Filter. Uses Phoenix Contact 1786488 and 1757323 connectors and 1206 L's and C's
PiFilter8.brd
author: Mike-Eng47
2 layer board of 1.93 x 2.12 inches (49.1 x 53.9 mm)
Uploaded:
October 28, 2016
Shared:
January 19, 2017
Total Price:
$20.45
8 channel Pi Filter for NI9203. Uses Phoenix Contact 1786488 and 1757323 connectors and 1206 L's and C's
8 channel Pi Filter for NI9203. Uses Phoenix Contact 1786488 and 1757323 connectors and 1206 L's and C's
24v Motor Controller
author: zackalak
2 layer board of 1.47 x 1.61 inches (37.3 x 41.0 mm)
Uploaded:
January 19, 2017
Shared:
January 19, 2017
Total Price:
$11.80
A 24v, high-powered motor controller. Some sort of active cooling is recommended.
A 24v, high-powered motor controller. Some sort of active cooling is recommended.
ICS43434_ButterflyAddOn.v01
author: PeskyProducts
2 layer board of 0.71 x 0.61 inches (17.9 x 15.4 mm)
Uploaded:
January 18, 2017
Shared:
January 18, 2017
Total Price:
$2.10
ICS43434 Digital I2S microphone add-on for Butterfly STM32L433 development board.
ICS43434 Digital I2S microphone add-on for Butterfly STM32L433 development board.
Fixed/Adjustable 500mA DC/DC
author: MarkOsborne
2 layer board of 0.80 x 0.60 inches (20.3 x 15.3 mm)
Uploaded:
January 18, 2017
Shared:
January 18, 2017
Total Price:
$2.40
500mA DC DC Buck Converter Based on TI TPS560200DBVR
BOM: U1: TPS560200DBVR L1: SRN6045-100M C1/C2: GRM319R61C106KE15D C3: 08053C104KAT2A C4: GRM21BR61C106KE15L Variable: VR1: TC33X-2-104E R3: 14K 0603 resistor Fixed 5V: R1: 105K 0603 resistor R2: 20K 0603 resistor
500mA DC DC Buck Converter Based on TI TPS560200DBVR
BOM: U1: TPS560200DBVR L1: SRN6045-100M C1/C2: GRM319R61C106KE15D C3: 08053C104KAT2A C4: GRM21BR61C106KE15L Variable: VR1: TC33X-2-104E R3: 14K 0603 resistor Fixed 5V: R1: 105K 0603 resistor R2: 20K 0603 resistor
Precision Rectifier V3
author: gryphonhouse
2 layer board of 2.50 x 2.00 inches (63.5 x 50.8 mm)
Uploaded:
January 18, 2017
Shared:
January 18, 2017
Total Price:
$25.00
Version 3 of the Precision Rectifier; corrects some issues.
Version 3 of the Precision Rectifier; corrects some issues.
HaveSome PCB V1.1
author: DeuxVis
2 layer board of 0.31 x 0.73 inches (7.8 x 18.6 mm)
Uploaded:
January 18, 2017
Shared:
January 18, 2017
Total Price:
$1.10
Small breakout board for many simple SMD components.
Inspired from Awesome PCB by Simon
Licensed under CC BY-NC-SA 3.0
Sources on [GitHub](https://github….
Show full description
Small breakout board for many simple SMD components.
Inspired from Awesome PCB by Simon
Licensed under CC BY-NC-SA 3.0
Sources on [GitHub](https://github….
Show full description
5-button arduino radio keyfob
author: bc547
2 layer board of 1.07 x 1.69 inches (27.1 x 43.0 mm)
Uploaded:
January 18, 2017
Shared:
January 18, 2017
Total Price:
$9.00
This board is meant to be placed in a CamdenBoss keyfob (Mfr code:2955-20R-5). It contains an Atmega328p arduino mcu, a RFM69 radiomodule, a RGB multicolor led for notifications and a CR2032 coincell holder.
Idle power consumption is measured to be a…
Show full description
This board is meant to be placed in a CamdenBoss keyfob (Mfr code:2955-20R-5). It contains an Atmega328p arduino mcu, a RFM69 radiomodule, a RGB multicolor led for notifications and a CR2032 coincell holder.
Idle power consumption is measured to be a…
Show full description
ICS43434.v01
author: PeskyProducts
2 layer board of 0.41 x 0.31 inches (10.3 x 7.8 mm)
Uploaded:
January 18, 2017
Shared:
January 18, 2017
Total Price:
$0.60
Breakout board for Invensense's latest low-power, bottom-ported I2S digital microphone.
Breakout board for Invensense's latest low-power, bottom-ported I2S digital microphone.
2 Player Arcade RPI3 PCB
author: GMcIvor
2 layer board of 2.76 x 2.45 inches (70.1 x 62.1 mm)
Uploaded:
January 17, 2017
Shared:
January 18, 2017
Total Price:
$33.75
A PCB designed for a raspberry pi 3 arcade cabinet I am building with my students. It has full 2 player controller support (recalbox os GPIO layout). This is version 1, updates will happen as more are made and feedback is given.
A PCB designed for a raspberry pi 3 arcade cabinet I am building with my students. It has full 2 player controller support (recalbox os GPIO layout). This is version 1, updates will happen as more are made and feedback is given.
Nes style Controller PCB
author: GMcIvor
2 layer board of 3.08 x 1.69 inches (78.1 x 43.0 mm)
Uploaded:
January 17, 2017
Shared:
January 18, 2017
Total Price:
$26.00
A Nes controller layout designed for the raspberry pi 3 and recalbox os (GPIO layout). It was designed for my Nes table, but can be utilized in other projects that needs this configuration. This is version 1, updates will happen as more are made and feedback is given.
A Nes controller layout designed for the raspberry pi 3 and recalbox os (GPIO layout). It was designed for my Nes table, but can be utilized in other projects that needs this configuration. This is version 1, updates will happen as more are made and feedback is given.
