DCHDMI Flex.kicad_pcb
2 layer board of 6.60 x 1.15 inches (167.5 x 29.3 mm)
Uploaded:
May 28, 2025
Shared:
May 28, 2025
Total Price:
$38.05
DCHDMI Solder on Flex for building or repairing your opensource DCHDMI Mod for the Dreamcast. Be sure to order this as a Flex and not a PCB.
Schematics with BOM can be found on Github.
All credit is due to chriz2600 and Citrus3000psi for creating this opensource mod. Be sure give them your supp…
Show full description
DCHDMI Solder on Flex for building or repairing your opensource DCHDMI Mod for the Dreamcast. Be sure to order this as a Flex and not a PCB.
Schematics with BOM can be found on Github.
All credit is due to chriz2600 and Citrus3000psi for creating this opensource mod. Be sure give them your supp…
Show full description
DCHDMI 1.3a PCB.kicad_pcb
4 layer board of 2.91 x 2.31 inches (74.0 x 58.8 mm)
Uploaded:
May 28, 2025
Shared:
May 28, 2025
Total Price:
$67.40
PCB for building or repairing your opensource DCHDMI Mod for the Dreamcast.
Schematics with BOM can be found on Github.
All credit is due to chriz2600 and Citrus3000psi for creating this opensource mod. Be sure give them your support.
PCB for building or repairing your opensource DCHDMI Mod for the Dreamcast.
Schematics with BOM can be found on Github.
All credit is due to chriz2600 and Citrus3000psi for creating this opensource mod. Be sure give them your support.
FRAM-SOIC flex for TurboDuo/PC Engine Duo by dshadoff
2 layer board of 0.93 x 0.81 inches (23.5 x 20.7 mm)
Uploaded:
November 10, 2022
Shared:
November 10, 2022
Total Price:
$3.75
This is an FRam mod made by David Shadoff for your TurboDuo/PC Engine Duo. This uses the FM16W08 Flash chip in the placement of the SRam chip. You will also have to remove the supercapacitor that powers the SRam chip. A11 and A12 are 0603 47Kohm Resistors. Make sure to order this as flex. The gui…
Show full description
This is an FRam mod made by David Shadoff for your TurboDuo/PC Engine Duo. This uses the FM16W08 Flash chip in the placement of the SRam chip. You will also have to remove the supercapacitor that powers the SRam chip. A11 and A12 are 0603 47Kohm Resistors. Make sure to order this as flex. The gui…
Show full description
