4by_switch_bank
2 layer board of 0.40 x 1.18 inches (10.2 x 30.0 mm)
Uploaded:
November 03, 2025
Shared:
November 20, 2025
Total Price:
$2.35
This is a breakout board for 4 - 6mm x 6 mm pushbutton switches. It fits a standard prototype bluggin board. I am using square header pins out the bottom to plug into the proto board and mounting the switches on top. Mount the switches first, bending over the tabs and solder. Pull extra pins f…
Show full description
This is a breakout board for 4 - 6mm x 6 mm pushbutton switches. It fits a standard prototype bluggin board. I am using square header pins out the bottom to plug into the proto board and mounting the switches on top. Mount the switches first, bending over the tabs and solder. Pull extra pins f…
Show full description
Common Mode Current Meter
2 layer board of 1.38 x 0.39 inches (35.0 x 10.0 mm)
Uploaded:
September 13, 2025
Shared:
October 29, 2025
Total Price:
$2.70
PCB3_gerber for common mode current meter, a ham radio test tool. KM5HT
PCB3_gerber for common mode current meter, a ham radio test tool. KM5HT
DigiPi-Power-Injector2
2 layer board of 0.91 x 0.69 inches (23.0 x 17.5 mm)
Uploaded:
February 17, 2022
Shared:
February 17, 2022
Total Price:
$3.10
DigiPi-Power-Injector and fan control using GPIO-27 http://craiger.org/digipi/ https://digipi.wiki/
Be sure to order this in a 2 oz board for the thinner profile.
DigiPi-Power-Injector and fan control using GPIO-27 http://craiger.org/digipi/ https://digipi.wiki/
Be sure to order this in a 2 oz board for the thinner profile.
PiHat-NPN-0805-ver3
2 layer board of 1.07 x 1.20 inches (27.2 x 30.4 mm)
Uploaded:
February 05, 2022
Shared:
February 05, 2022
Total Price:
$6.35
Not responsible for any damage to your equipment. This circuit is experimental! Proceed with caution. This is a companion board to the Digipi - http://craiger.org/digipi/ It has the LED/PTT circuits for the project.
73 Steve, KM5HT
Not responsible for any damage to your equipment. This circuit is experimental! Proceed with caution. This is a companion board to the Digipi - http://craiger.org/digipi/ It has the LED/PTT circuits for the project.
73 Steve, KM5HT
PiHat-NPN-1206-ver3
2 layer board of 1.07 x 1.20 inches (27.2 x 30.4 mm)
Uploaded:
February 05, 2022
Shared:
February 05, 2022
Total Price:
$6.35
Not responsible for any damage to your equipment. This circuit is experimental! Proceed with caution. This is a companion board to the Digipi - http://craiger.org/digipi/ It has the LED/PTT circuits for the project.
73 Steve, KM5HT
Not responsible for any damage to your equipment. This circuit is experimental! Proceed with caution. This is a companion board to the Digipi - http://craiger.org/digipi/ It has the LED/PTT circuits for the project.
73 Steve, KM5HT
