power-breakout.kicad_pcb

2 layer board of 0.90 x 2.05 inches (22.9 x 52.1 mm)
Uploaded: February 9th 2023
Shared: January 10th 2024
Total Price: $9.20

A basic breadboard crouton for distributing power from your Eurorack power supply.

A basic breadboard crouton for distributing power from your Eurorack power supply.

Embeddable link to order this shared Project

vco.kicad_pcb

2 layer board of 2.39 x 9.16 inches (60.6 x 232.7 mm)
Uploaded: February 15th 2023
Shared: January 2nd 2024
Total Price: $109.25

A Voltage Contolled Oscillator based on the Yusynth VCO.

A Voltage Contolled Oscillator based on the Yusynth VCO.

Embeddable link to order this shared Project

LED_Strand_Interface.kicad_pcb

2 layer board of 2.75 x 4.20 inches (70.0 x 106.8 mm)
Uploaded: April 13th 2018
Shared: April 14th 2018
Total Price: $57.85

Power distribution and IR control for fairy lights using ATMega328P

find all the code, KiCAD files, and BOM on github

Power distribution and IR control for fairy lights using ATMega328P

find all the code, KiCAD files, and BOM on github
