Shared Projects by elandahl

Shared Projects by elandahl

Eric Landahl

4 layer board of 2.56 x 2.21 inches (65.1 x 56.1 mm)
Uploaded: March 9th 2018
Shared: March 28th 2019
Total Price: $56.60

For shot-by-shot x-ray bunch intensity monitor at Pohang Accelerator Lab X-ray Free-Electron Laser, South Korea. By Ellie Martin-Eberhardt, DePaul University Physics Department

For shot-by-shot x-ray bunch intensity monitor at Pohang Accelerator Lab X-ray Free-Electron Laser, South Korea. By Ellie Martin-Eberhardt, DePaul University Physics Department

Embeddable link to order this shared Project

CounterModule-0_8.kicad_pcb

2 layer board of 2.56 x 2.21 inches (65.1 x 56.1 mm)
Uploaded: February 16th 2019
Shared: February 16th 2019
Total Price: $28.30

Raspberry Pi Dual-channel counter with logic, RasPi HAT format by Ellie Martin-Eberhardt.

Raspberry Pi Dual-channel counter with logic, RasPi HAT format by Ellie Martin-Eberhardt.

Embeddable link to order this shared Project

multiSPI_v21

2 layer board of 2.49 x 2.90 inches (63.2 x 73.7 mm)
Uploaded: August 20th 2018
Shared: August 20th 2018
Total Price: $36.05

multiple SPI (> 2) SPI devices on Raspberry Pi. In this case, 4x MCP3008 ADCs. Seehttps://github.com/elandahl/multiSPI This version uses surface mount components and has extra outputs (shift register, CEs, and SPI)

multiple SPI (> 2) SPI devices on Raspberry Pi. In this case, 4x MCP3008 ADCs. Seehttps://github.com/elandahl/multiSPI This version uses surface mount components and has extra outputs (shift register, CEs, and SPI)

Embeddable link to order this shared Project

multiSPIschematic2

2 layer board of 3.05 x 2.69 inches (77.5 x 68.3 mm)
Uploaded: July 30th 2018
Shared: July 30th 2018
Total Price: $40.95

multiple SPI (> 2) SPI devices on Raspberry Pi. In this case, 4x MCP3008 ADCs. Seehttps://github.com/elandahl/multiSPI

multiple SPI (> 2) SPI devices on Raspberry Pi. In this case, 4x MCP3008 ADCs. Seehttps://github.com/elandahl/multiSPI

Embeddable link to order this shared Project
