mini-extender-m2

2 layer board of 5.91 x 1.58 inches (150.0 x 40.1 mm)
Uploaded: March 15th 2022
Shared: April 12th 2022
Total Price: $46.65

Embeddable link to order this shared Project

68K_34_pin_header_j20.kicad_pcb

2 layer board of 0.87 x 1.24 inches (22.2 x 31.4 mm)
Uploaded: November 19th 2021
Shared: January 19th 2022
Total Price: $5.40

20 pin"Y" repeater (ignore the file name)

20 pin"Y" repeater (ignore the file name)

Embeddable link to order this shared Project

68k_pin-headers.kicad_pcb

2 layer board of 0.99 x 2.73 inches (25.2 x 69.3 mm)
Uploaded: November 19th 2021
Shared: January 19th 2022
Total Price: $13.50

50 pin "Y" repeater pcb

50 pin "Y" repeater pcb

Embeddable link to order this shared Project

68K_34_pin_header_j2.kicad_pcb

2 layer board of 0.88 x 1.89 inches (22.4 x 48.0 mm)
Uploaded: November 19th 2021
Shared: January 19th 2022
Total Price: $8.30

34 pin "Y" repeater pcb

34 pin "Y" repeater pcb
