APA CharliePlex Grid
2 layer board of 2.50 x 1.10 inches (63.5 x 27.9 mm)
Uploaded:
July 22, 2016
Shared:
September 22, 2016
Total Price:
$13.75
Digits for Adafruit.com driver board. I got distracted and never even ordered it. Contact me if you want to pick it up.
Digits for Adafruit.com driver board. I got distracted and never even ordered it. Contact me if you want to pick it up.
IoT Clock V0.2
2 layer board of 1.98 x 0.75 inches (50.3 x 19.1 mm)
Uploaded:
April 11, 2016
Shared:
April 11, 2016
Total Price:
$7.40
ESP8266 gets NTP sync. Antenna traces designed for 0.8mm board with 2oz copper.
ESP8266 gets NTP sync. Antenna traces designed for 0.8mm board with 2oz copper.
REDOUBLER v0.3
2 layer board of 1.25 x 0.53 inches (31.8 x 13.4 mm)
Uploaded:
March 15, 2015
Shared:
March 15, 2015
Total Price:
$3.25
Open RNG Had to add 3.3V regulator. Moved programming pads to bottom to make space.
Open RNG Had to add 3.3V regulator. Moved programming pads to bottom to make space.
