irid.kicad_pcb

Top
Bottom

2 layer board of 10.40 x 3.82 inches (264.1 x 97.1 mm)
Uploaded: February 16, 2026
Shared: February 16, 2026
Total Price: $198.80

3 patch array for iridium satellite constellation.

3 patch array for iridium satellite constellation.

Top
Bottom
  • Actions

      Ordering shared project

      Hey there! Before ordering, make sure you have all the info you need to complete and use this design. This usually means a component list, and sometimes additional information such as assembly notes, source code, or usage guides.
      Since this is a project designed by a community member, it may contain design errors that prevent it from working as intended. OSH Park cannot place any guarantees about the functionality or correctness of the design.
      Order Board
    • Order Board
    • Download
    • Permalink
    • Embed link
Embeddable link to order this shared Project

Patch_Array_V3.kicad_pcb

Top
Bottom

2 layer board of 21.99 x 3.54 inches (558.5 x 90.0 mm)
Uploaded: December 12, 2025
Shared: December 12, 2025
Total Price: $389.60

Version 3 of 8 Element Dual-feed Patch Array Antenna

Version 3 of 8 Element Dual-feed Patch Array Antenna

Top
Bottom
