Tunable IR based proximity sensor with a digital output
- Autodesk Eagle .brd and .sch files included with all non-standard libs
- Sample Arduino Code also included
- Potentiometer used to adjust the range
- Detection range of about 9cm (3.5 in)
[GitHub link](https://github.c…
Tunable IR based proximity sensor with a digital output
- Autodesk Eagle .brd and .sch files included with all non-standard libs
- Sample Arduino Code also included
- Potentiometer used to adjust the range
- Detection range of about 9cm (3.5 in)
GitHub link
Important Notes:
- The 220 Ω resistor is a pull-up in parallel with the LED. The LED needs to be one with an internal resistance (Standard RED 5mm LED with internal resistance is recommended)
- The board has a normal HIGH and triggered LOW. The LED will be ON when the sensor hasn’t been triggered and will turn OFF when it has.
BOM:
| |
|
|
| Part |
Part no. |
Quantity |
| IR Reflective Sensor |
TCRT 5000 |
1 |
| Red LED (internal resistor) |
|
1 |
| 100 ohm Resistor |
|
1 |
| 220 ohm Resistor |
|
1 |
| 4.7k ohm Resistor |
|
1 |
| 10k Multi-turn POT |
|
1 |
| 0.1uF Ceramic Capacitor |
|
2 |
| TL081 op-amp |
TL081 |
1 |
| LM311N op-amp |
LM311N |
1 |
| Break Away Headers |
|
6 |
Schematic
Prototype Board
BreadBoard based testing
