BQ2000 v3.brd
2 layer board of 1.48 x 1.48 inches (37.5 x 37.5 mm)
Uploaded:
December 13, 2016
Shared:
December 13, 2016
Total Price:
$10.90
This is an as yet untested, reduced version of the BQ2000 evaluation board. I've pulled off the jumper pins and greatly simplified the schematic.
I've made a few versions of this board so I'm fairly confident this version will work.
Eagle files for this board can be found [here](https://gi…
