Shuri-Clone 1.0

2 layer board of 1.10 x 0.96 inches (27.9 x 24.3 mm).
Uploaded: May 14th, 2019 16:10.
Shared: June 13th, 2019 17:03
Total Price: $5.25

Top

Bottom

BOM:

Reference	Description
U1	XC9572XL-10VQG44C
U2	M25…

Permalink Embed link

Download Order Board

Embeddable link to order this shared Project

Shuri-Clone 1.0

2 layer board of 1.10 x 0.96 inches (27.9 x 24.3 mm).
Uploaded: May 14th, 2019 16:10.
Shared: June 13th, 2019 17:03
Total Price: $5.25

BOM:

Reference	Description
U1	XC9572XL-10VQG44C
U2	M25…

Permalink Embed link

Download Order Board

Embeddable link to order this shared Project

Project Permalink URL

GBFlasher Micro 1.3

4 layer board of 1.90 x 0.85 inches (48.2 x 21.5 mm).
Uploaded: June 6th, 2019 22:18.
Shared: June 6th, 2019 22:21
Total Price: $16.10

Top

Bottom

The worlds smallest Game Boy cart flasher!

A clone of [J.Rodrigo's flasher](https://www.tindie.com/products/JRodri…

The worlds smallest Game Boy cart flasher!

A clone of J.Rodrigo’s flasher

BOM

Reference	Part Number	Description
C1	0603ZD104KAT2A	0.1uF
C2	0603ZD104KAT2A	0.1uF
C3	NMC0603X5R106M10	10uF
C4	0603ZD104KAT2A	0.1uF
C5	C0603C220J5RACTU	22pF
C6	C0603C220J5RACTU	22pF
Atmega8515	Atmega8515L-8AU
FT232RL	FT232RL
J1	E10103594-0001LF	Micro USB Receptacle
J2	Buy from Aliexpress	Cartridge Reader
LED1	LSM0603453V	Green 0603 LED
LED2	LSM0603463V	Blue 0603 LED
LED3	LSM0603463V	Blue 0603 LED
LED4	LSM0603412V	Red 0603 LED
PTC1	MF-FSMF050X-2	500mA PTC Fuse
R1	ERJ-PB3D1001V	1K
R2	ERJ-PB3D1001V	1K
R3	ERJ-PB3D1001V	1K
R4	ERJ-PB3D1001V	1K
R5	NTR06B1002DTRF	10K
XTAL1	FQ1045A-6.000 or FC8AQCCMM6.0-T1	6MHz Crystal

1.1 Changelog:

Added indicators for the chips and header to make the pcb easier to assemble
Added indicator for LED positioning
Reduced pcb height by 0.3mm
Fixed positioning of cartridge reader guide holes
Renamed IC1 and IC3 to make more sense

1.2 Changelog:

Reduced pcb height by 1.4mm
Relocated componetnts to fit within the new size
Modified footprint for cart reader
Replaced the crystal (ECS-60-32-5PXDN-TR) with FQ1045A-6.000 to as this component is only 1.7mm tall instead of 4.3mm

1.3 Changelog:

Fixed incorrect crystal footprint

Permalink Embed link

Download Order Board

Embeddable link to order this shared Project

GBFlasher Micro 1.3

4 layer board of 1.90 x 0.85 inches (48.2 x 21.5 mm).
Uploaded: June 6th, 2019 22:18.
Shared: June 6th, 2019 22:21
Total Price: $16.10

The worlds smallest Game Boy cart flasher!

A clone of [J.Rodrigo's flasher](https://www.tindie.com/products/JRodri…

The worlds smallest Game Boy cart flasher!

A clone of J.Rodrigo’s flasher

BOM

Reference	Part Number	Description
C1	0603ZD104KAT2A	0.1uF
C2	0603ZD104KAT2A	0.1uF
C3	NMC0603X5R106M10	10uF
C4	0603ZD104KAT2A	0.1uF
C5	C0603C220J5RACTU	22pF
C6	C0603C220J5RACTU	22pF
Atmega8515	Atmega8515L-8AU
FT232RL	FT232RL
J1	E10103594-0001LF	Micro USB Receptacle
J2	Buy from Aliexpress	Cartridge Reader
LED1	LSM0603453V	Green 0603 LED
LED2	LSM0603463V	Blue 0603 LED
LED3	LSM0603463V	Blue 0603 LED
LED4	LSM0603412V	Red 0603 LED
PTC1	MF-FSMF050X-2	500mA PTC Fuse
R1	ERJ-PB3D1001V	1K
R2	ERJ-PB3D1001V	1K
R3	ERJ-PB3D1001V	1K
R4	ERJ-PB3D1001V	1K
R5	NTR06B1002DTRF	10K
XTAL1	FQ1045A-6.000 or FC8AQCCMM6.0-T1	6MHz Crystal

1.1 Changelog:

Added indicators for the chips and header to make the pcb easier to assemble
Added indicator for LED positioning
Reduced pcb height by 0.3mm
Fixed positioning of cartridge reader guide holes
Renamed IC1 and IC3 to make more sense

1.2 Changelog:

Reduced pcb height by 1.4mm
Relocated componetnts to fit within the new size
Modified footprint for cart reader
Replaced the crystal (ECS-60-32-5PXDN-TR) with FQ1045A-6.000 to as this component is only 1.7mm tall instead of 4.3mm

1.3 Changelog:

Fixed incorrect crystal footprint

Permalink Embed link

Download Order Board

Embeddable link to order this shared Project

Project Permalink URL

GBFlasher Plug 1.1

2 layer board of 2.28 x 0.85 inches (57.9 x 21.5 mm).
Uploaded: June 5th, 2019 18:45.
Shared: June 5th, 2019 18:54
Total Price: $9.60

Top

Bottom

Who needs cables anyways?

A clone of [J.Rodrigo's flasher](https://www.tindie.com/products/JRodrigo/cart-flasher-f…

Who needs cables anyways?

A clone of J.Rodrigo’s flasher

BOM

Reference	Part Number	Description
C1	0603ZD104KAT2A	0.1uF
C2	0603ZD104KAT2A	0.1uF
C3	NMC0603X5R106M10	10uF
C4	0603ZD104KAT2A	0.1uF
C5	C0603C220J5RACTU	22pF
C6	C0603C220J5RACTU	22pF
U1	Atmega8515L-8AU
U2	FT232RL
J1	0480372100	USB Type A Plug
J2	Buy from Aliexpress	Cartridge Reader
LED1	LSM0603412V	Red 0603 LED
LED2	LSM0603463V	Blue 0603 LED
LED3	LSM0603463V	Blue 0603 LED
LED4	LSM0603453V	Green 0603 LED
PTC1	MF-FSMF050X-2	500mA PTC Fuse
R1	ERJ-PB3D1001V	1K
R2	ERJ-PB3D1001V	1K
R3	ERJ-PB3D1001V	1K
R4	ERJ-PB3D1001V	1K
R5	NTR06B1002DTRF	10K
X1	FQ1045A-6.000	6MHz Crystal

1.1 Changelog:

Changed IC Reference to U
Changed reference XTAL1 to X1
Reduced board height by 1,7mm
Reduced board width by 4,3mm
Replaced crystal with a lower profile one
Added orientation indication for FT232RL
Added indicator for led orientation
Reduced board cost by 1,55 USD

Permalink Embed link

Download Order Board

Embeddable link to order this shared Project

GBFlasher Plug 1.1

2 layer board of 2.28 x 0.85 inches (57.9 x 21.5 mm).
Uploaded: June 5th, 2019 18:45.
Shared: June 5th, 2019 18:54
Total Price: $9.60

Who needs cables anyways?

A clone of [J.Rodrigo's flasher](https://www.tindie.com/products/JRodrigo/cart-flasher-f…

Who needs cables anyways?

A clone of J.Rodrigo’s flasher

BOM

Reference	Part Number	Description
C1	0603ZD104KAT2A	0.1uF
C2	0603ZD104KAT2A	0.1uF
C3	NMC0603X5R106M10	10uF
C4	0603ZD104KAT2A	0.1uF
C5	C0603C220J5RACTU	22pF
C6	C0603C220J5RACTU	22pF
U1	Atmega8515L-8AU
U2	FT232RL
J1	0480372100	USB Type A Plug
J2	Buy from Aliexpress	Cartridge Reader
LED1	LSM0603412V	Red 0603 LED
LED2	LSM0603463V	Blue 0603 LED
LED3	LSM0603463V	Blue 0603 LED
LED4	LSM0603453V	Green 0603 LED
PTC1	MF-FSMF050X-2	500mA PTC Fuse
R1	ERJ-PB3D1001V	1K
R2	ERJ-PB3D1001V	1K
R3	ERJ-PB3D1001V	1K
R4	ERJ-PB3D1001V	1K
R5	NTR06B1002DTRF	10K
X1	FQ1045A-6.000	6MHz Crystal

1.1 Changelog:

Changed IC Reference to U
Changed reference XTAL1 to X1
Reduced board height by 1,7mm
Reduced board width by 4,3mm
Replaced crystal with a lower profile one
Added orientation indication for FT232RL
Added indicator for led orientation
Reduced board cost by 1,55 USD

Permalink Embed link

Download Order Board

Embeddable link to order this shared Project

Project Permalink URL

GBFlasher Micro 1.2

4 layer board of 1.90 x 0.85 inches (48.2 x 21.5 mm).
Uploaded: May 19th, 2019 21:27.
Shared: May 19th, 2019 21:30
Total Price: $16.10

Top

Bottom

The worlds smallest Game Boy cart flasher!

A clone of [J.Rodrigo's flasher](https://www.tindie.com/products/JRodri…

The worlds smallest Game Boy cart flasher!

A clone of J.Rodrigo’s flasher

BOM

Reference	Part Number	Description
C1	0603ZD104KAT2A	0.1uF
C2	0603ZD104KAT2A	0.1uF
C3	NMC0603X5R106M10	10uF
C4	0603ZD104KAT2A	0.1uF
C5	C0603C220J5RACTU	22pF
C6	C0603C220J5RACTU	22pF
Atmega8515	Atmega8515L-8AU
FT232RL	FT232RL
J1	E10103594-0001LF	Micro USB Receptacle
J2	Buy from Aliexpress	Cartridge Reader
LED1	LSM0603453V	Green 0603 LED
LED2	LSM0603463V	Blue 0603 LED
LED3	LSM0603463V	Blue 0603 LED
LED4	LSM0603412V	Red 0603 LED
PTC1	MF-FSMF050X-2	500mA PTC Fuse
R1	ERJ-PB3D1001V	1K
R2	ERJ-PB3D1001V	1K
R3	ERJ-PB3D1001V	1K
R4	ERJ-PB3D1001V	1K
R5	NTR06B1002DTRF	10K
XTAL1	FQ1045A-6.000	6MHz Crystal

1.1 Changelog:

Added indicators for the chips and header to make the pcb easier to assemble
Added indicator for LED positioning
Reduced pcb height by 0.3mm
Fixed positioning of cartridge reader guide holes
Renamed IC1 and IC3 to make more sense

1.2 Changelog:

Reduced pcb height by 1.4mm
Relocated componetnts to fit within the new size
Modified footprint for cart reader
Replaced the crystal (ECS-60-32-5PXDN-TR) with FQ1045A-6.000 to as this component is only 1.7mm tall instead of 4.3mm

Permalink Embed link

Download Order Board

Embeddable link to order this shared Project

GBFlasher Micro 1.2

4 layer board of 1.90 x 0.85 inches (48.2 x 21.5 mm).
Uploaded: May 19th, 2019 21:27.
Shared: May 19th, 2019 21:30
Total Price: $16.10

The worlds smallest Game Boy cart flasher!

A clone of [J.Rodrigo's flasher](https://www.tindie.com/products/JRodri…

The worlds smallest Game Boy cart flasher!

A clone of J.Rodrigo’s flasher

BOM

Reference	Part Number	Description
C1	0603ZD104KAT2A	0.1uF
C2	0603ZD104KAT2A	0.1uF
C3	NMC0603X5R106M10	10uF
C4	0603ZD104KAT2A	0.1uF
C5	C0603C220J5RACTU	22pF
C6	C0603C220J5RACTU	22pF
Atmega8515	Atmega8515L-8AU
FT232RL	FT232RL
J1	E10103594-0001LF	Micro USB Receptacle
J2	Buy from Aliexpress	Cartridge Reader
LED1	LSM0603453V	Green 0603 LED
LED2	LSM0603463V	Blue 0603 LED
LED3	LSM0603463V	Blue 0603 LED
LED4	LSM0603412V	Red 0603 LED
PTC1	MF-FSMF050X-2	500mA PTC Fuse
R1	ERJ-PB3D1001V	1K
R2	ERJ-PB3D1001V	1K
R3	ERJ-PB3D1001V	1K
R4	ERJ-PB3D1001V	1K
R5	NTR06B1002DTRF	10K
XTAL1	FQ1045A-6.000	6MHz Crystal

1.1 Changelog:

Added indicators for the chips and header to make the pcb easier to assemble
Added indicator for LED positioning
Reduced pcb height by 0.3mm
Fixed positioning of cartridge reader guide holes
Renamed IC1 and IC3 to make more sense

1.2 Changelog:

Reduced pcb height by 1.4mm
Relocated componetnts to fit within the new size
Modified footprint for cart reader
Replaced the crystal (ECS-60-32-5PXDN-TR) with FQ1045A-6.000 to as this component is only 1.7mm tall instead of 4.3mm

Permalink Embed link

Download Order Board

Embeddable link to order this shared Project

Project Permalink URL

GBFlasher Micro 1.1

4 layer board of 1.90 x 0.90 inches (48.2 x 22.9 mm).
Uploaded: May 12th, 2019 02:17.
Shared: May 12th, 2019 02:19
Total Price: $17.10

Top

Bottom

The worlds smallest Game Boy cart flasher!

A clone of [J.Rodrigo's flasher](https://www.tindie.com/products/JRodri…

The worlds smallest Game Boy cart flasher!

A clone of J.Rodrigo’s flasher

BOM

Reference	Part Number	Description
C1	0603ZD104KAT2A	0.1uF
C2	0603ZD104KAT2A	0.1uF
C3	NMC0603X5R106M10	10uF
C4	0603ZD104KAT2A	0.1uF
C5	C0603C220J5RACTU	22pF
C6	C0603C220J5RACTU	22pF
Atmega8515	Atmega8515L-8AU
FT232RL	FT232RL
J1	E10103594-0001LF	Micro USB Receptacle
J2	Buy from Aliexpress	Cartridge Reader
LED1	LSM0603453V	Green 0603 LED
LED2	LSM0603463V	Blue 0603 LED
LED3	LSM0603463V	Blue 0603 LED
LED4	LSM0603412V	Red 0603 LED
PTC1	MF-FSMF050X-2	500mA PTC Fuse
R1	ERJ-PB3D1001V	1K
R2	ERJ-PB3D1001V	1K
R3	ERJ-PB3D1001V	1K
R4	ERJ-PB3D1001V	1K
R5	NTR06B1002DTRF	10K
XTAL1	ECS-60-32-5PXDN-TR	6MHz 0603 Crystal

1.1 Changelog:

Added indicators for the chips and header to make the pcb easier to assemble
Added indicator for LED positioning
Reduced pcb height by 0.3mm
Fixed positioning of cartridge reader guide holes
Renamed IC1 and IC3 to make more sense

Permalink Embed link

Download Order Board

Embeddable link to order this shared Project

GBFlasher Micro 1.1

4 layer board of 1.90 x 0.90 inches (48.2 x 22.9 mm).
Uploaded: May 12th, 2019 02:17.
Shared: May 12th, 2019 02:19
Total Price: $17.10

The worlds smallest Game Boy cart flasher!

A clone of [J.Rodrigo's flasher](https://www.tindie.com/products/JRodri…

The worlds smallest Game Boy cart flasher!

A clone of J.Rodrigo’s flasher

BOM

Reference	Part Number	Description
C1	0603ZD104KAT2A	0.1uF
C2	0603ZD104KAT2A	0.1uF
C3	NMC0603X5R106M10	10uF
C4	0603ZD104KAT2A	0.1uF
C5	C0603C220J5RACTU	22pF
C6	C0603C220J5RACTU	22pF
Atmega8515	Atmega8515L-8AU
FT232RL	FT232RL
J1	E10103594-0001LF	Micro USB Receptacle
J2	Buy from Aliexpress	Cartridge Reader
LED1	LSM0603453V	Green 0603 LED
LED2	LSM0603463V	Blue 0603 LED
LED3	LSM0603463V	Blue 0603 LED
LED4	LSM0603412V	Red 0603 LED
PTC1	MF-FSMF050X-2	500mA PTC Fuse
R1	ERJ-PB3D1001V	1K
R2	ERJ-PB3D1001V	1K
R3	ERJ-PB3D1001V	1K
R4	ERJ-PB3D1001V	1K
R5	NTR06B1002DTRF	10K
XTAL1	ECS-60-32-5PXDN-TR	6MHz 0603 Crystal

1.1 Changelog:

Added indicators for the chips and header to make the pcb easier to assemble
Added indicator for LED positioning
Reduced pcb height by 0.3mm
Fixed positioning of cartridge reader guide holes
Renamed IC1 and IC3 to make more sense

Permalink Embed link

Download Order Board

Embeddable link to order this shared Project

Project Permalink URL

Reference	Description
U1	XC9572XL-10VQG44C
U2	M25P40-VMN3TPB
R1	10K 0603
R2	10K 0603
R3	10K 0603
R4	470 0603
C1	0.1uF
C2	1uF

Profile for HDR

Shared projects

Shuri-Clone 1.0

Shuri-Clone 1.0

GBFlasher Micro 1.3

GBFlasher Micro 1.3

GBFlasher Plug 1.1

GBFlasher Plug 1.1

GBFlasher Micro 1.2

GBFlasher Micro 1.2

GBFlasher Micro 1.1

GBFlasher Micro 1.1
