Mid Morse Beacon 2
2 layer board of 2.33 x 0.77 inches (59.1 x 19.5 mm)
Uploaded:
November 23, 2015
Shared:
January 05, 2016
Total Price:
$8.90
Diminutive FM “fox” transmitter capable of up to 100 mW of output power.
Bill of materials: http://www.mouser.com/ProjectManager/ProjectDetail.aspx?AccessID=0a724f6ca0
Kicad drawings and MSP430 source code: http://dbindner.freeshell.org/kicad/MidMorseBeacon2/
Source code was written for …
Show full description
Diminutive FM “fox” transmitter capable of up to 100 mW of output power.
Bill of materials: http://www.mouser.com/ProjectManager/ProjectDetail.aspx?AccessID=0a724f6ca0
Kicad drawings and MSP430 source code: http://dbindner.freeshell.org/kicad/MidMorseBeacon2/
Source code was written for …
Show full description
Tiny Morse Beacon rev 3
2 layer board of 2.46 x 0.66 inches (62.5 x 16.9 mm)
Uploaded:
October 27, 2015
Shared:
October 27, 2015
Total Price:
$8.15
A very low power 10 to 20mW beacon for radio direction finding. A bill of materials is available at:
<http://www.mouser.com/ProjectManager/ProjectDetail.aspx?AccessID=06ba8c9ddb>
Schematic: <http://dbindner.freeshell.org/kicad/TinyMorseBeacon.pdf>
Kicad files are at: <http://db…
Show full description
A very low power 10 to 20mW beacon for radio direction finding. A bill of materials is available at:
<http://www.mouser.com/ProjectManager/ProjectDetail.aspx?AccessID=06ba8c9ddb>
Schematic: <http://dbindner.freeshell.org/kicad/TinyMorseBeacon.pdf>
Kicad files are at: <http://db…
Show full description
DRA818 daughter card version 1.2
2 layer board of 1.90 x 1.97 inches (48.2 x 50.1 mm)
Uploaded:
August 12, 2015
Shared:
August 12, 2015
Total Price:
$18.70
Plugs into balloon radio card to provide a transmitter. (This version with resistors in the PTT and Enable lines).
Plugs into balloon radio card to provide a transmitter. (This version with resistors in the PTT and Enable lines).
APRS companion
2 layer board of 2.48 x 0.70 inches (63.0 x 17.9 mm)
Uploaded:
July 22, 2015
Shared:
July 22, 2015
Total Price:
$8.70
Decodes APRS audio from your radio and sends it via bluetooth to your phone or laptop. Requires an Inland Arduino Mini Pro, and an HC-05 bluetooth card.
Decodes APRS audio from your radio and sends it via bluetooth to your phone or laptop. Requires an Inland Arduino Mini Pro, and an HC-05 bluetooth card.
