Consoles Unleashed Sony PlayStation SIO-XS is a Quick Solder Switchboard for Cybdyn Systems PSIO PlayStation flash cartridge based on Voultar’s SIO-X.

It simplifies the install of a PSIO Switchboard by reducing the wires needed and making the entire install much cleaner.

SIO-X is a great design, but for my own uses I prefer a separate modchip and switchboard. For this reason I decided to design the SIO-XS.

SIO-XS simplifies Voultar’s design by omitting the modchip and changing the layout a little. SIO-XS was designed from the ground up but is based entirely on Voultar’s work on SIO-X. So all credit to Voultar and his original design.

Voultar’s SIO-X license is included with this download.

v1.0 - 30/09/2021 v1.1 - 10/06/2023

Sega Genesis 3 - VA2.

Function Restore Helper Board.

Standard v1.1

Sega Genesis 3 function restore helper boards are designed to make wiring easier and cleaner when restoring the removed functions from Sega Genesis 3 consoles. Especially useful for “VA1” revision which requires soldering between the cartridge port plastic and PCB which can be difficult to do well.

0.8mm PCB Max.

Sega Genesis 3 - VA2.

Function Restore Helper Board.

Mini v1.1

Sega Genesis 3 function restore helper boards are designed to make wiring easier and cleaner when restoring the removed functions from Sega Genesis 3 consoles. Especially useful for “VA1” revision which requires soldering between the cartridge port plastic and PCB which can be difficult to do well.

0.8mm PCB Max.

Sega Genesis 3 - VA1.

Function Restore Helper Board.

Mini v1.1

Sega Genesis 3 function restore helper boards are designed to make wiring easier and cleaner when restoring the removed functions from Sega Genesis 3 consoles. Especially useful for “VA1” revision which requires soldering between the cartridge port plastic and PCB which can be difficult to do well.

0.8mm PCB Max.

Sega Genesis 3 - VA1.

Function Restore Helper Board.

Standard v1.1

Sega Genesis 3 function restore helper boards are designed to make wiring easier and cleaner when restoring the removed functions from Sega Genesis 3 consoles. Especially useful for “VA1” revision which requires soldering between the cartridge port plastic and PCB which can be difficult to do well.

0.8mm PCB Max.
