Cage trainer controller V2.2
2 layer board of 2.70 x 2.10 inches (68.7 x 53.4 mm)
Uploaded:
October 31, 2022
Shared:
December 25, 2022
Total Price:
$28.40
For Trainer project. This is an Arduino Uno Shield that allows both an Arduino Uno and an Adafruit Trinket M0 control a peristaltic pump.
For Trainer project. This is an Arduino Uno Shield that allows both an Arduino Uno and an Adafruit Trinket M0 control a peristaltic pump.
Filter for optical sensor V1
2 layer board of 1.24 x 0.67 inches (31.4 x 17.0 mm)
Uploaded:
March 31, 2022
Shared:
December 25, 2022
Total Price:
$4.10
Power supply bypass and low pass filter for Sharp GP2Y0A41SK0F analog optical distance sensor. Recommended values are C1,C2: 10uf; R1: 160 ohms.
Power supply bypass and low pass filter for Sharp GP2Y0A41SK0F analog optical distance sensor. Recommended values are C1,C2: 10uf; R1: 160 ohms.
PlayVideo interface box V2.0
2 layer board of 3.15 x 0.79 inches (80.1 x 20.1 mm)
Uploaded:
February 10, 2021
Shared:
March 16, 2021
Total Price:
$12.45
Interface for Raspberry Pi 4 with power start and stop pushbuttons and fan control.
Interface for Raspberry Pi 4 with power start and stop pushbuttons and fan control.
