RGB LED Ring V2.1 - commit dd7eec60
author: madworm
2 layer board of 1.72 x 1.72 inches (43.7 x 43.7 mm)
Uploaded:
August 17, 2013
Shared:
August 17, 2013
Total Price:
$14.75
8x RGB LED + MBI5168(7) drivers + ATmega168. Optionally populated with PLCC 3528 LEDs (single colour). Optional TSOP38238 38kHz IR receiver.
Show full description
8x RGB LED + MBI5168(7) drivers + ATmega168. Optionally populated with PLCC 3528 LEDs (single colour). Optional TSOP38238 38kHz IR receiver.
4 Pin Audio Jack
author: blinkyblinky
2 layer board of 0.79 x 0.68 inches (20.1 x 17.3 mm)
Uploaded:
October 20, 2012
Shared:
August 16, 2013
Total Price:
$2.65
An audio adapter for various projects that prevents the need to use a new 3.5mm jack each time and allows any speaker or headphone to be connected.
An audio adapter for various projects that prevents the need to use a new 3.5mm jack each time and allows any speaker or headphone to be connected.
CC3000 Breakout
author: stottsc
4 layer board of 1.41 x 1.51 inches (35.7 x 38.4 mm)
Uploaded:
July 14, 2013
Shared:
August 16, 2013
Total Price:
$21.20
4 layer CC3000 module breakout board with appropriate antenna microstrip. Uses ceramic antenna from TI example boards.
4 layer CC3000 module breakout board with appropriate antenna microstrip. Uses ceramic antenna from TI example boards.
Wireless sensor node
author: tkircher
2 layer board of 2.09 x 2.89 inches (53.1 x 73.5 mm)
Uploaded:
August 13, 2013
Shared:
August 15, 2013
Total Price:
$30.25
This is a wireless sensor node, designed around a Microchip PIC18F45J10 microcontroller and an MRF89XAM9A (915MHz) wireless module. As of April 2018, the three prototype modules have been operating continuously for four years. One of the modules is connected to a computer via serial interface to …
Show full description
This is a wireless sensor node, designed around a Microchip PIC18F45J10 microcontroller and an MRF89XAM9A (915MHz) wireless module. As of April 2018, the three prototype modules have been operating continuously for four years. One of the modules is connected to a computer via serial interface to …
Show full description
BurnBabyBurn v1.0
author: johnboiles
2 layer board of 0.71 x 1.75 inches (18.0 x 44.4 mm)
Uploaded:
August 14, 2013
Shared:
August 14, 2013
Total Price:
$6.15
Tiny board for controlling a high-power logic-level n-channel MOSFET transistor. Useful for burning stuff (like nichrome wire). BurnBabyBurn on GitHub
Tiny board for controlling a high-power logic-level n-channel MOSFET transistor. Useful for burning stuff (like nichrome wire). BurnBabyBurn on GitHub
produinoboy led board
author: alleybeachelectric
2 layer board of 1.05 x 0.36 inches (26.7 x 9.2 mm)
Uploaded:
August 14, 2013
Shared:
August 14, 2013
Total Price:
$1.85
daughter board for produinoboy
daughter board for produinoboy
Cmoy Amp
author: alleybeachelectric
2 layer board of 1.02 x 2.02 inches (25.8 x 51.2 mm)
Uploaded:
September 15, 2012
Shared:
August 14, 2013
Total Price:
$10.20
8x8x8
author: alleybeachelectric
2 layer board of 3.94 x 3.36 inches (100.1 x 85.3 mm)
Uploaded:
January 02, 2013
Shared:
August 14, 2013
Total Price:
$66.10
8x8x8 led cube
8x8x8 led cube
UsbVia [B1313]
author: jmedved
2 layer board of 1.27 x 0.79 inches (32.2 x 20.1 mm)
Uploaded:
April 01, 2013
Shared:
August 14, 2013
Total Price:
$5.00
UsbVia is small board that exposes USB contacts to allow for easier multimeter measurements. There are four 2 mm connectors (two for current and two for voltage measurement) that allow for direct multimeter probe connection.
Details at [https://bitbucket.org/jmedved/usbvia/](https://bitbucket….
Show full description
UsbVia is small board that exposes USB contacts to allow for easier multimeter measurements. There are four 2 mm connectors (two for current and two for voltage measurement) that allow for direct multimeter probe connection.
Details at [https://bitbucket.org/jmedved/usbvia/](https://bitbucket….
Show full description
